2016 Ford F-150 towing capacity.

Published towing ratings for the 2016 F-150 run from 4,900 - 12,200 lbs depending on engine, tow type, cab, axle ratio, wheelbase, drivetrain, and equipment.

Find your exact towing capacity Run the 2016 lookup tool → Check towing capacity by VIN Decode your VIN to prefill the 2016 lookup → View full comparison chart Jump to the full rating chart →

Retrieved from official Ford 2016 RV & Trailer Guide publications. Citations available below.

2016 Ford F-150 towing capacity chart

Engine Chart

2.7L GTDI V6

7,300 – 8,500 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.31	4x2	122 in	12,200 lbs	7,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x2	141 in	12,300 lbs	7,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	122 in	12,500 lbs	7,700 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	141 in	12,500 lbs	7,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	122 in	13,100 lbs	8,500 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	141 in	13,100 lbs	8,400 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	141 in	13,300 lbs	8,500 lbs	Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	122 in	13,300 lbs	8,500 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x4	141 in	13,300 lbs	8,200 lbs	Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	141 in	13,300 lbs	8,400 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
SuperCab
3.31	4x2	145 in	12,500 lbs	7,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x2	164 in	12,600 lbs	7,500 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	145 in	12,700 lbs	7,500 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	145 in	13,100 lbs	8,200 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	145 in	13,300 lbs	8,300 lbs	Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x2	164 in	13,100 lbs	8,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	164 in	13,300 lbs	8,200 lbs	Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	145 in	13,300 lbs	8,000 lbs	Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	145 in	13,300 lbs	8,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
SuperCrew
3.31	4x2	145 in	12,600 lbs	7,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x2	157 in	12,600 lbs	7,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	145 in	12,800 lbs	7,500 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	145 in	13,100 lbs	8,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	145 in	13,300 lbs	8,200 lbs	Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x2	157 in	13,100 lbs	8,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	157 in	13,300 lbs	8,200 lbs	Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	145 in	13,300 lbs	8,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x4	145 in	13,300 lbs	8,000 lbs	Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16

Towing Capacity Chart

5th-Wheel / Gooseneck Towing

Regular Cab
3.31	4x2	122 in	12,200 lbs	7,500 lbs		p.17
3.31	4x2	141 in	12,300 lbs	7,500 lbs		p.17
3.55	4x4	122 in	12,500 lbs	7,600 lbs		p.17
3.55	4x4	141 in	12,500 lbs	7,500 lbs		p.17
3.73	4x2	122 in	13,100 lbs	8,400 lbs		p.17
3.73	4x2	141 in	13,100 lbs	8,300 lbs		p.17
3.73	4x2	141 in	13,300 lbs	8,400 lbs	2.7L EcoBoost Payload Package Row evidence · direct source · p.17	p.17
3.73	4x4	122 in	13,300 lbs	7,700 lbs		p.17
3.73	4x4	141 in	13,300 lbs	8,100 lbs	2.7L EcoBoost Payload Package Row evidence · direct source · p.17	p.17
3.73	4x4	141 in	13,300 lbs	8,300 lbs		p.17
SuperCab
3.31	4x2	145 in	12,500 lbs	7,500 lbs		p.17
3.31	4x2	164 in	12,600 lbs	7,400 lbs		p.17
3.55	4x4	145 in	12,700 lbs	7,400 lbs		p.17
3.73	4x2	145 in	13,100 lbs	7,900 lbs		p.17
3.73	4x2	145 in	13,300 lbs	8,200 lbs	2.7L EcoBoost Payload Package Row evidence · direct source · p.17	p.17
3.73	4x2	164 in	13,100 lbs	7,700 lbs		p.17
3.73	4x2	164 in	13,300 lbs	8,100 lbs	2.7L EcoBoost Payload Package Row evidence · direct source · p.17	p.17
3.73	4x4	145 in	13,300 lbs	7,600 lbs		p.17
3.73	4x4	145 in	13,300 lbs	7,900 lbs	2.7L EcoBoost Payload Package Row evidence · direct source · p.17	p.17
SuperCrew
3.31	4x2	145 in	12,600 lbs	7,500 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.31	4x2	157 in	12,600 lbs	7,500 lbs		p.17
3.55	4x4	145 in	12,800 lbs	7,300 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.73	4x2	145 in	13,100 lbs	7,500 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.73	4x2	145 in	13,300 lbs	8,100 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + 2.7L EcoBoost Payload Package Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.73	4x2	157 in	13,100 lbs	7,900 lbs		p.17
3.73	4x2	157 in	13,300 lbs	8,100 lbs	2.7L EcoBoost Payload Package Row evidence · direct source · p.17	p.17
3.73	4x4	145 in	13,300 lbs	7,300 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.73	4x4	145 in	13,300 lbs	7,900 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + 2.7L EcoBoost Payload Package Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17

Engine Chart

3.5L 4-Valve V6

4,900 – 7,600 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.55	4x2	122 in	9,400 lbs	5,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x2	141 in	9,500 lbs	5,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	122 in	9,700 lbs	5,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	122 in	12,000 lbs	7,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	141 in	12,100 lbs	7,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x4	122 in	12,200 lbs	7,500 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x4	141 in	12,200 lbs	7,400 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
SuperCab
3.55	4x2	145 in	9,800 lbs	5,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	145 in	12,200 lbs	7,400 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x4	145 in	12,200 lbs	7,200 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
SuperCrew
3.55	4x2	145 in	9,900 lbs	5,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	145 in	12,200 lbs	7,300 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x4	145 in	12,200 lbs	7,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16

Towing Capacity Chart

5th-Wheel / Gooseneck Towing

Regular Cab
3.55	4x2	122 in	9,400 lbs	4,900 lbs		p.17
3.55	4x2	141 in	9,500 lbs	4,900 lbs		p.17
3.55	4x4	122 in	9,700 lbs	4,900 lbs		p.17
3.73	4x2	122 in	12,000 lbs	7,500 lbs		p.17
3.73	4x2	141 in	12,100 lbs	7,500 lbs		p.17
3.73	4x4	122 in	12,200 lbs	7,400 lbs		p.17
3.73	4x4	141 in	12,200 lbs	7,300 lbs		p.17
SuperCab
3.55	4x2	145 in	9,800 lbs	4,900 lbs		p.17
3.73	4x2	145 in	12,200 lbs	7,300 lbs		p.17
3.73	4x4	145 in	12,200 lbs	7,100 lbs		p.17
SuperCrew
3.55	4x2	145 in	9,900 lbs	4,900 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.73	4x2	145 in	12,200 lbs	7,200 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.73	4x4	145 in	12,200 lbs	7,000 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17

Engine Chart

3.5L GTDI V6

6,600 – 12,200 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.15	4x2	141 in	15,500 lbs	10,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	141 in	15,800 lbs	10,700 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x2	141 in	17,100 lbs	12,200 lbs	Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x4	141 in	15,800 lbs	10,700 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	141 in	17,100 lbs	12,000 lbs	Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x2	141 in	17,100 lbs	12,000 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	141 in	17,000 lbs	11,800 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	141 in	17,100 lbs	11,800 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
SuperCab
3.15	4x2	145 in	15,800 lbs	10,700 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.15	4x2	164 in	15,900 lbs	10,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	145 in	16,000 lbs	10,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	164 in	16,200 lbs	10,700 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x2	145 in	17,100 lbs	12,000 lbs	Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x2	164 in	17,100 lbs	11,800 lbs	Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x4	145 in	16,000 lbs	10,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	145 in	17,100 lbs	11,700 lbs	Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x4	164 in	16,200 lbs	10,700 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	164 in	17,100 lbs	11,600 lbs	Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x2	164 in	17,100 lbs	11,700 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	164 in	17,100 lbs	11,500 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
SuperCrew
3.15	4x2	145 in	15,800 lbs	10,400 lbs	Weight-distributing hitch + Limited trim only Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.15	4x2	145 in	15,800 lbs	10,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.15	4x2	157 in	15,900 lbs	10,700 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	145 in	16,100 lbs	10,400 lbs	Weight-distributing hitch + Limited trim only Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.31	4x4	145 in	16,100 lbs	10,700 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	157 in	16,100 lbs	10,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x2	145 in	16,600 lbs	11,200 lbs	Weight-distributing hitch + Limited trim only Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x2	145 in	17,000 lbs	11,800 lbs	Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x2	157 in	17,100 lbs	11,900 lbs	Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x4	145 in	16,100 lbs	10,700 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	145 in	16,700 lbs	11,000 lbs	Weight-distributing hitch + Limited trim only Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x4	145 in	16,900 lbs	11,500 lbs	Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x4	157 in	16,100 lbs	10,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	157 in	17,100 lbs	11,600 lbs	Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x2	157 in	17,100 lbs	11,700 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	157 in	17,000 lbs	11,400 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	157 in	17,100 lbs	11,400 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16

Towing Capacity Chart

5th-Wheel / Gooseneck Towing

Regular Cab
3.15	4x2	141 in	15,500 lbs	10,500 lbs		p.17
3.31	4x4	141 in	15,800 lbs	10,500 lbs		p.17
3.55	4x2	141 in	17,000 lbs	12,000 lbs	Max Trailer Tow Package Row evidence · direct source · p.17	p.17
3.55	4x2	141 in	17,100 lbs	12,100 lbs	Max Trailer Tow Package Row evidence · direct source · p.17	p.17
3.55	4x4	141 in	15,800 lbs	10,500 lbs		p.17
3.55	4x4	141 in	17,100 lbs	11,800 lbs	Max Trailer Tow Package Row evidence · direct source · p.17	p.17
3.73	4x2	141 in	17,100 lbs	11,900 lbs	Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x2	141 in	17,100 lbs	12,000 lbs	Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x4	141 in	17,000 lbs	11,700 lbs	Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x4	141 in	17,100 lbs	11,700 lbs	Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Row evidence · direct source · p.17	p.17
SuperCab
3.15	4x2	145 in	15,800 lbs	10,300 lbs		p.17
3.15	4x2	164 in	15,900 lbs	10,500 lbs		p.17
3.31	4x4	145 in	16,000 lbs	10,100 lbs		p.17
3.31	4x4	164 in	16,200 lbs	9,600 lbs		p.17
3.55	4x2	145 in	17,100 lbs	10,300 lbs	Max Trailer Tow Package Row evidence · direct source · p.17	p.17
3.55	4x2	164 in	17,100 lbs	11,400 lbs	Max Trailer Tow Package Row evidence · direct source · p.17	p.17
3.55	4x4	145 in	16,000 lbs	10,100 lbs		p.17
3.55	4x4	145 in	17,100 lbs	10,100 lbs	Max Trailer Tow Package Row evidence · direct source · p.17	p.17
3.55	4x4	164 in	16,200 lbs	9,600 lbs		p.17
3.55	4x4	164 in	17,100 lbs	9,600 lbs	Max Trailer Tow Package Row evidence · direct source · p.17	p.17
3.73	4x2	164 in	17,100 lbs	11,600 lbs	Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x2	164 in	17,100 lbs	11,700 lbs	Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x4	164 in	17,100 lbs	11,400 lbs	Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels + 18 in tires and wheels Row evidence · direct source · p.17	p.17
SuperCrew
3.15	4x2	145 in	15,800 lbs	8,300 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Limited trim only Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.15	4x2	145 in	15,800 lbs	10,000 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.15	4x2	157 in	15,900 lbs	10,200 lbs		p.17
3.31	4x4	145 in	16,100 lbs	6,600 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Limited trim only Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.31	4x4	145 in	16,100 lbs	9,800 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.31	4x4	157 in	16,100 lbs	9,900 lbs		p.17
3.55	4x2	145 in	16,600 lbs	8,300 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Limited trim only Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.55	4x2	145 in	17,000 lbs	10,000 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Max Trailer Tow Package Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.55	4x2	157 in	17,100 lbs	10,200 lbs	Max Trailer Tow Package Row evidence · direct source · p.17	p.17
3.55	4x4	145 in	16,700 lbs	6,600 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Limited trim only Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.55	4x4	145 in	16,100 lbs	9,800 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.55	4x4	145 in	16,900 lbs	9,800 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Max Trailer Tow Package Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.55	4x4	157 in	16,100 lbs	9,900 lbs		p.17
3.55	4x4	157 in	17,100 lbs	9,900 lbs	Max Trailer Tow Package Row evidence · direct source · p.17	p.17
3.73	4x2	157 in	17,100 lbs	11,600 lbs	Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels + 18 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x4	157 in	17,000 lbs	11,300 lbs	Heavy-Duty Payload Package + Max Trailer Tow Package + 17 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x4	157 in	17,100 lbs	11,300 lbs	Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Row evidence · direct source · p.17	p.17

Engine Chart

5.0L 4-Valve V8

6,800 – 11,100 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.31	4x2	122 in	13,000 lbs	8,300 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x2	141 in	13,900 lbs	9,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	122 in	13,200 lbs	8,300 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	141 in	14,100 lbs	9,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x2	122 in	13,800 lbs	9,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x2	141 in	14,900 lbs	10,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	122 in	13,200 lbs	8,300 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	141 in	14,100 lbs	9,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	141 in	16,000 lbs	11,000 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + 17 in tires and wheels + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	122 in	14,600 lbs	9,600 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x4	141 in	16,100 lbs	10,900 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + 17 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	141 in	16,200 lbs	10,900 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	141 in	16,200 lbs	11,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
SuperCab
3.31	4x2	145 in	12,000 lbs	6,900 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.31	4x2	145 in	14,200 lbs	9,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x2	164 in	14,300 lbs	9,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	145 in	14,300 lbs	9,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	164 in	14,300 lbs	8,800 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x2	145 in	13,500 lbs	8,400 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x2	145 in	15,200 lbs	10,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x2	164 in	15,300 lbs	10,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	145 in	13,500 lbs	8,200 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x4	145 in	14,400 lbs	9,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	164 in	14,500 lbs	9,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	164 in	16,200 lbs	10,800 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + 17 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x2	164 in	16,200 lbs	10,900 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	145 in	14,000 lbs	8,600 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	145 in	16,200 lbs	10,900 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x4	164 in	16,200 lbs	10,600 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + 17 in tires and wheels + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	164 in	16,200 lbs	10,700 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
SuperCrew
3.31	4x2	145 in	12,000 lbs	6,900 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.31	4x2	145 in	14,200 lbs	9,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x2	157 in	12,000 lbs	6,900 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.31	4x2	157 in	14,200 lbs	9,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	145 in	14,300 lbs	8,900 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.31	4x4	157 in	14,300 lbs	8,900 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x2	145 in	13,500 lbs	8,400 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x2	145 in	15,200 lbs	10,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x2	157 in	13,500 lbs	8,400 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x2	157 in	15,200 lbs	10,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	145 in	13,500 lbs	8,100 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x4	145 in	14,400 lbs	9,000 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.55	4x4	157 in	13,500 lbs	8,100 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.55	4x4	157 in	14,500 lbs	9,100 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x2	157 in	16,200 lbs	10,800 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + 17 in tires and wheels + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	145 in	14,000 lbs	8,600 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	145 in	16,200 lbs	10,800 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16
3.73	4x4	157 in	14,000 lbs	8,600 lbs	Weight-distributing hitch + Sport Package Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	157 in	16,200 lbs	10,500 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + 17 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	157 in	16,200 lbs	10,600 lbs	Weight-distributing hitch + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.16	p.16
3.73	4x4	157 in	16,200 lbs	10,800 lbs	Weight-distributing hitch Section evidence · source-bound expansion · p.16	p.16

Towing Capacity Chart

5th-Wheel / Gooseneck Towing

Regular Cab
3.31	4x2	122 in	13,000 lbs	8,200 lbs		p.17
3.31	4x2	141 in	13,900 lbs	8,900 lbs		p.17
3.31	4x4	122 in	13,200 lbs	8,200 lbs		p.17
3.31	4x4	141 in	14,100 lbs	8,900 lbs		p.17
3.55	4x2	122 in	13,800 lbs	9,000 lbs		p.17
3.55	4x2	141 in	14,900 lbs	9,900 lbs		p.17
3.55	4x4	122 in	13,200 lbs	8,200 lbs		p.17
3.55	4x4	141 in	14,100 lbs	8,900 lbs		p.17
3.73	4x2	141 in	16,000 lbs	10,900 lbs	Heavy-Duty Payload Package + 17 in tires and wheels + 18 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x4	122 in	14,600 lbs	9,100 lbs		p.17
3.73	4x4	141 in	16,200 lbs	10,700 lbs		p.17
3.73	4x4	141 in	16,100 lbs	10,800 lbs	Heavy-Duty Payload Package + 17 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x4	141 in	16,200 lbs	10,800 lbs	Heavy-Duty Payload Package + 18 in tires and wheels Row evidence · direct source · p.17	p.17
SuperCab
3.31	4x2	145 in	12,000 lbs	6,800 lbs	Sport Package Row evidence · direct source · p.17	p.17
3.31	4x2	145 in	14,200 lbs	9,000 lbs		p.17
3.31	4x2	164 in	14,300 lbs	9,000 lbs		p.17
3.31	4x4	145 in	14,300 lbs	8,900 lbs		p.17
3.31	4x4	164 in	14,300 lbs	8,700 lbs		p.17
3.55	4x2	145 in	13,500 lbs	8,300 lbs	Sport Package Row evidence · direct source · p.17	p.17
3.55	4x2	145 in	15,200 lbs	10,000 lbs		p.17
3.55	4x2	164 in	15,300 lbs	10,000 lbs		p.17
3.55	4x4	145 in	13,500 lbs	8,100 lbs	Sport Package Row evidence · direct source · p.17	p.17
3.55	4x4	145 in	14,400 lbs	8,900 lbs		p.17
3.55	4x4	164 in	14,500 lbs	8,900 lbs		p.17
3.73	4x2	164 in	16,200 lbs	10,800 lbs	Heavy-Duty Payload Package + 17 in tires and wheels + 18 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x4	145 in	14,000 lbs	8,500 lbs	Sport Package Row evidence · direct source · p.17	p.17
3.73	4x4	145 in	16,200 lbs	10,400 lbs		p.17
3.73	4x4	164 in	16,200 lbs	9,600 lbs		p.17
3.73	4x4	164 in	16,200 lbs	10,500 lbs	18 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x4	164 in	16,200 lbs	10,600 lbs	Heavy-Duty Payload Package + 17 in tires and wheels Row evidence · direct source · p.17	p.17
SuperCrew
3.31	4x2	145 in	12,000 lbs	6,800 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Sport Package Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.31	4x2	145 in	14,200 lbs	9,000 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.31	4x2	157 in	12,000 lbs	6,800 lbs	Sport Package Row evidence · direct source · p.17	p.17
3.31	4x2	157 in	14,200 lbs	9,000 lbs		p.17
3.31	4x4	145 in	14,300 lbs	8,800 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.31	4x4	157 in	14,300 lbs	8,800 lbs		p.17
3.55	4x2	145 in	13,500 lbs	8,300 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Sport Package Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.55	4x2	145 in	15,200 lbs	10,000 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.55	4x2	157 in	13,500 lbs	8,300 lbs	Sport Package Row evidence · direct source · p.17	p.17
3.55	4x2	157 in	15,200 lbs	10,000 lbs		p.17
3.55	4x4	145 in	13,500 lbs	8,000 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Sport Package Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.55	4x4	145 in	14,400 lbs	8,900 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.55	4x4	157 in	13,500 lbs	8,000 lbs	Sport Package Row evidence · direct source · p.17	p.17
3.55	4x4	157 in	14,500 lbs	8,900 lbs		p.17
3.73	4x2	157 in	16,200 lbs	10,700 lbs	Heavy-Duty Payload Package + 17 in tires and wheels + 18 in tires and wheels Row evidence · direct source · p.17	p.17
3.73	4x4	145 in	14,000 lbs	8,500 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Sport Package Column evidence / Row evidence · source-bound expansion / direct source · p.17	p.17
3.73	4x4	145 in	16,200 lbs	10,100 lbs	145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Column evidence · source-bound expansion · p.17	p.17
3.73	4x4	157 in	14,000 lbs	8,500 lbs	Sport Package Row evidence · direct source · p.17	p.17
3.73	4x4	157 in	16,200 lbs	10,300 lbs		p.17
3.73	4x4	157 in	16,200 lbs	10,400 lbs	Heavy-Duty Payload Package + 17 in tires and wheels + 18 in tires and wheels Row evidence · direct source · p.17	p.17

POWERTRAIN

Towing Capacity by Engine

Your engine determines your base towing limit and which max-tow packages are available. Start here to see the 2016 ratings for your specific truck setup.

Ford’s towing charts sometimes use technical engine labels. We show the familiar engine name first and Ford’s chart label alongside it so you can match both.

Highest Capacity

3.5L GTDI V6

Range: 6,600 - 12,200 lbs

Max conventional tow 12,200 LBS

5.0L 4-Valve V8

Range: 6,800 - 11,100 lbs

Max conventional tow 11,100 LBS

2.7L GTDI V6

Range: 7,300 - 8,500 lbs

Max conventional tow 8,500 LBS

3.5L 4-Valve V6

Range: 4,900 - 7,600 lbs

Max conventional tow 7,600 LBS

Guide policy

Guide rules included

Trailers over 5,000 lbs require Trailer Tow Package or Max Trailer Tow Package. Other guide pages are cited below but are not converted into universal requirements for this year.

Rows

Chart labels stay specific

Requirement labels in the table come from Ford chart cells, section notes, and footnotes for the matching row.

Navigation

Trim pages stay separate

The 2016 trim shortcuts are not published here. Use year, engine, cab, drivetrain, axle, GCWR, and wheelbase filters to narrow the chart.

Technical Audit

Data sources

These citations show the Ford guide pages used to build the 2016 overview.

Show source pages for the 2016 guide

DOC_ID: ford-tow DOCUMENT BASIS

Ford RV & Trailer Towing Guide 2016

Audit Scope PAGES: 13-17, 28-32

PDF Creation Date 2015-10-02
