2019 Ford F-150 towing capacity.

Published towing ratings for the 2019 F-150 run from 5,000 - 13,200 lbs depending on engine, tow type, cab, axle ratio, wheelbase, drivetrain, and equipment.

Find your exact towing capacity Run the 2019 lookup tool → Check towing capacity by VIN Decode your VIN to prefill the 2019 lookup → View full comparison chart Jump to the full rating chart →

Retrieved from official Ford 2019 RV & Trailer Guide publications. Citations available below.

2019 Ford F-150 Blueprint
2019 TOWING RANGE
5,000 - 13,200 LBS
CONVENTIONAL MAX
13,200 LBS
5TH-WHEEL MAX
12,100 LBS
2019 Ford F-150 towing capacity chart
Engine Chart

2.7L GTDI V6

7,400 – 9,000 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.55 4x2 122 in 12,300 lbs 7,600 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 141 in 12,300 lbs 7,600 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x4 122 in 12,500 lbs 7,600 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x4 141 in 12,600 lbs 7,600 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x2 122 in 13,200 lbs 8,500 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x2 141 in 13,200 lbs 8,500 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x2 141 in 13,400 lbs 8,500 lbs Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x4 122 in 13,300 lbs 8,400 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x4 141 in 13,300 lbs 8,300 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x4 141 in 14,100 lbs 9,000 lbs Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
SuperCab
3.55 4x2 145 in 12,700 lbs 7,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 164 in 12,600 lbs 7,500 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x4 145 in 12,900 lbs 7,600 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x2 145 in 13,300 lbs 8,300 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x2 145 in 13,300 lbs 8,300 lbs Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x2 164 in 13,300 lbs 8,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x2 164 in 14,200 lbs 9,000 lbs Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x4 145 in 13,300 lbs 8,000 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x4 145 in 14,300 lbs 9,000 lbs Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
SuperCrew
3.55 4x2 145 in 12,800 lbs 7,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 157 in 12,800 lbs 7,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x4 145 in 12,900 lbs 7,600 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x2 145 in 13,300 lbs 8,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x2 145 in 13,300 lbs 8,200 lbs Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x2 157 in 13,300 lbs 8,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x2 157 in 14,100 lbs 9,000 lbs Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x4 145 in 13,300 lbs 8,000 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.73 4x4 145 in 14,300 lbs 8,900 lbs Weight-distributing hitch + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
Towing Capacity Chart

5th-Wheel / Gooseneck Towing

Regular Cab
3.55 4x2 122 in 12,300 lbs 7,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x2 141 in 12,300 lbs 7,500 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x4 122 in 12,500 lbs 7,500 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x4 141 in 12,600 lbs 7,500 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.73 4x2 122 in 13,200 lbs 8,500 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.73 4x2 141 in 13,200 lbs 8,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.73 4x2 141 in 13,400 lbs 8,500 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x4 122 in 13,300 lbs 8,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.73 4x4 141 in 13,300 lbs 8,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.73 4x4 141 in 14,100 lbs 8,900 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
SuperCab
3.55 4x2 145 in 12,700 lbs 7,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x2 164 in 12,600 lbs 7,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x4 145 in 12,900 lbs 7,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.73 4x2 145 in 13,300 lbs 8,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x2 145 in 13,300 lbs 8,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.73 4x2 164 in 13,300 lbs 8,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.73 4x2 164 in 14,200 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x4 145 in 13,300 lbs 7,900 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.73 4x4 145 in 14,300 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
SuperCrew
3.55 4x2 145 in 12,800 lbs 7,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.21 p.21
3.55 4x2 157 in 12,800 lbs 7,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x4 145 in 12,900 lbs 7,500 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.21 p.21
3.73 4x2 145 in 13,300 lbs 7,800 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.21 p.21
3.73 4x2 145 in 13,300 lbs 8,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + 2.7L EcoBoost Payload Package Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x2 157 in 13,300 lbs 8,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.73 4x2 157 in 14,100 lbs 8,900 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2.7L EcoBoost Payload Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x4 145 in 13,300 lbs 7,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.21 p.21
3.73 4x4 145 in 14,300 lbs 8,900 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + 2.7L EcoBoost Payload Package Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
Engine Chart

3.0L Turbo Diesel V6

7,200 – 11,500 lbs Engine page →

Towing Capacity Chart

Conventional towing

SuperCab
3.31 4x2 145 in 15,700 lbs 10,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x4 145 in 16,000 lbs 10,100 lbs Weight-distributing hitch + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.31 4x4 145 in 16,000 lbs 10,200 lbs Weight-distributing hitch + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x2 145 in 17,100 lbs 11,500 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x4 145 in 16,000 lbs 10,100 lbs Weight-distributing hitch + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x4 145 in 16,000 lbs 10,200 lbs Weight-distributing hitch + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x4 145 in 17,100 lbs 11,200 lbs Weight-distributing hitch + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x4 145 in 17,100 lbs 11,300 lbs Weight-distributing hitch + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
SuperCrew
3.31 4x2 145 in 15,900 lbs 10,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x2 157 in 15,900 lbs 10,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x4 145 in 16,100 lbs 10,100 lbs Weight-distributing hitch + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.31 4x4 145 in 16,100 lbs 10,300 lbs Weight-distributing hitch + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.31 4x4 157 in 16,100 lbs 10,100 lbs Weight-distributing hitch + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.31 4x4 157 in 16,100 lbs 10,300 lbs Weight-distributing hitch + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x2 145 in 17,100 lbs 11,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x2 157 in 17,100 lbs 11,300 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x4 145 in 16,100 lbs 10,100 lbs Weight-distributing hitch + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x4 145 in 16,100 lbs 10,300 lbs Weight-distributing hitch + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x4 145 in 17,100 lbs 10,900 lbs Weight-distributing hitch + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x4 145 in 17,100 lbs 11,300 lbs Weight-distributing hitch + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x4 157 in 16,100 lbs 10,100 lbs Weight-distributing hitch + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x4 157 in 16,100 lbs 10,300 lbs Weight-distributing hitch + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x4 157 in 17,100 lbs 11,100 lbs Weight-distributing hitch + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.55 4x4 157 in 17,100 lbs 11,300 lbs Weight-distributing hitch + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
Towing Capacity Chart

5th-Wheel / Gooseneck Towing

SuperCab
3.31 4x2 145 in 15,700 lbs 9,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x4 145 in 16,000 lbs 7,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.31 4x4 145 in 16,000 lbs 8,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x2 145 in 17,100 lbs 9,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x4 145 in 16,000 lbs 7,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x4 145 in 17,100 lbs 7,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x4 145 in 16,000 lbs 8,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x4 145 in 17,100 lbs 8,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
SuperCrew
3.31 4x2 145 in 15,900 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
3.31 4x2 157 in 15,900 lbs 8,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x4 145 in 16,100 lbs 7,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + 2-speed automatic 4WD transmission Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.31 4x4 145 in 16,100 lbs 8,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Electronic Shift-On-The-Fly transmission Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.31 4x4 157 in 16,100 lbs 7,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.31 4x4 157 in 16,100 lbs 8,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x2 145 in 17,100 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
3.55 4x2 157 in 17,100 lbs 8,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x4 145 in 16,100 lbs 7,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + 2-speed automatic 4WD transmission Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x4 145 in 17,100 lbs 7,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + 2-speed automatic 4WD transmission Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x4 145 in 16,100 lbs 8,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Electronic Shift-On-The-Fly transmission Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x4 145 in 17,100 lbs 8,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Electronic Shift-On-The-Fly transmission Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x4 157 in 16,100 lbs 7,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x4 157 in 17,100 lbs 7,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 2-speed automatic 4WD transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x4 157 in 16,100 lbs 8,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.55 4x4 157 in 17,100 lbs 8,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Electronic Shift-On-The-Fly transmission Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
Engine Chart

3.3L PFDI V6

5,000 – 7,700 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.55 4x2 122 in 9,600 lbs 5,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x2 141 in 9,700 lbs 5,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x4 122 in 9,800 lbs 5,000 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x2 122 in 12,200 lbs 7,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x2 141 in 12,300 lbs 7,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x4 122 in 12,300 lbs 7,500 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x4 141 in 12,300 lbs 7,400 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
SuperCab
3.55 4x2 145 in 9,900 lbs 5,000 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x2 145 in 12,300 lbs 7,400 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x4 145 in 12,500 lbs 7,400 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
SuperCrew
3.55 4x2 145 in 10,000 lbs 5,000 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x2 145 in 12,400 lbs 7,400 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x4 145 in 12,600 lbs 7,400 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
Towing Capacity Chart

5th-Wheel / Gooseneck Towing

Regular Cab
3.55 4x2 122 in 9,600 lbs 5,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x2 141 in 9,700 lbs 5,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x4 122 in 9,800 lbs 5,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x2 122 in 12,200 lbs 7,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x2 141 in 12,300 lbs 7,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x4 122 in 12,300 lbs 7,500 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x4 141 in 12,300 lbs 7,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
SuperCab
3.55 4x2 145 in 9,900 lbs 5,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x2 145 in 12,300 lbs 7,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x4 145 in 12,500 lbs 7,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
SuperCrew
3.55 4x2 145 in 10,000 lbs 5,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
3.73 4x2 145 in 12,400 lbs 7,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
3.73 4x4 145 in 12,600 lbs 7,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
Engine Chart

3.5L GTDI V6

6,000 – 13,200 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.15 4x2 141 in 15,500 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.31 4x4 141 in 15,900 lbs 10,800 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 141 in 15,500 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 141 in 17,000 lbs 12,100 lbs Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.55 4x4 141 in 15,900 lbs 10,800 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x4 141 in 17,100 lbs 12,000 lbs Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x2 141 in 17,100 lbs 12,000 lbs Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x4 141 in 17,100 lbs 11,800 lbs Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
SuperCab
3.15 4x2 145 in 15,800 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.15 4x2 164 in 15,900 lbs 10,600 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.31 4x4 145 in 16,100 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.31 4x4 164 in 16,200 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 145 in 15,800 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 145 in 17,100 lbs 12,000 lbs Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.55 4x2 164 in 15,900 lbs 10,600 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 164 in 17,100 lbs 11,800 lbs Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.55 4x4 145 in 16,100 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x4 145 in 17,100 lbs 11,700 lbs Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.55 4x4 164 in 16,200 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x4 164 in 17,100 lbs 11,600 lbs Weight-distributing hitch + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x2 164 in 17,100 lbs 11,700 lbs Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x4 164 in 17,100 lbs 11,500 lbs Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
4.10 4x4 133 in 12,050 lbs 6,000 lbs Weight-distributing hitch + Raptor trim only + 133 in wheelbase Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
SuperCrew
3.15 4x2 145 in 15,900 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.15 4x2 157 in 15,900 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.31 4x4 145 in 16,200 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.31 4x4 157 in 16,200 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 145 in 15,900 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 145 in 16,700 lbs 11,100 lbs Weight-distributing hitch + Limited trim only Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.55 4x2 145 in 17,900 lbs 12,700 lbs Weight-distributing hitch + Max Trailer Tow Package + 20 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.55 4x2 157 in 15,900 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x2 157 in 18,400 lbs 13,200 lbs Weight-distributing hitch + Max Trailer Tow Package + 20 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.55 4x4 145 in 16,700 lbs 9,400 lbs Weight-distributing hitch + Limited trim only Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.55 4x4 145 in 16,200 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x4 145 in 18,200 lbs 12,700 lbs Weight-distributing hitch + Max Trailer Tow Package + 20 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.55 4x4 157 in 16,200 lbs 10,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.19 p.19
3.55 4x4 157 in 18,400 lbs 12,900 lbs Weight-distributing hitch + Max Trailer Tow Package + 20 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x2 157 in 17,100 lbs 11,700 lbs Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
3.73 4x4 157 in 17,100 lbs 11,500 lbs Weight-distributing hitch + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
4.10 4x4 145 in 14,250 lbs 8,000 lbs Weight-distributing hitch + Raptor trim only Section evidence / Row evidence · source-bound expansion / direct source · p.19 p.19
Towing Capacity Chart

5th-Wheel / Gooseneck Towing

Regular Cab
3.15 4x2 141 in 15,500 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.31 4x4 141 in 15,900 lbs 10,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x2 141 in 15,500 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x2 141 in 17,000 lbs 12,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.55 4x4 141 in 15,900 lbs 10,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x4 141 in 17,100 lbs 11,900 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x2 141 in 17,100 lbs 12,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x4 141 in 17,100 lbs 11,800 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
SuperCab
3.15 4x2 145 in 15,800 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.15 4x2 164 in 15,900 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.31 4x4 145 in 16,100 lbs 10,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.31 4x4 164 in 16,200 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x2 145 in 15,800 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x2 145 in 17,100 lbs 10,800 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.55 4x2 164 in 15,900 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x2 164 in 17,100 lbs 11,800 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.55 4x4 145 in 16,100 lbs 10,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x4 145 in 17,100 lbs 10,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.55 4x4 164 in 16,200 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x4 164 in 17,100 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Max Trailer Tow Package Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x2 164 in 17,100 lbs 11,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x4 164 in 17,100 lbs 11,500 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
SuperCrew
3.15 4x2 145 in 15,900 lbs 10,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.21 p.21
3.15 4x2 157 in 15,900 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.31 4x4 145 in 16,200 lbs 10,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.21 p.21
3.31 4x4 157 in 16,200 lbs 10,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x2 145 in 16,700 lbs 7,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Limited trim only Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.55 4x2 145 in 15,900 lbs 10,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.21 p.21
3.55 4x2 145 in 17,900 lbs 10,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Max Trailer Tow Package + 20 in tires and wheels Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.55 4x2 157 in 15,900 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x2 157 in 18,400 lbs 11,800 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Max Trailer Tow Package + 20 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.55 4x4 145 in 16,700 lbs 6,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Limited trim only Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.55 4x4 145 in 16,200 lbs 10,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.21 p.21
3.55 4x4 145 in 18,200 lbs 10,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit + Max Trailer Tow Package + 20 in tires and wheels Section evidence / Column evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.55 4x4 157 in 16,200 lbs 10,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.21 p.21
3.55 4x4 157 in 18,400 lbs 10,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Max Trailer Tow Package + 20 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x2 157 in 17,100 lbs 11,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
3.73 4x4 157 in 17,100 lbs 11,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + Max Trailer Tow Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.21 p.21
Engine Chart

5.0L 4-Valve V8

8,300 – 11,500 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.15 4x2 122 in 13,100 lbs 8,400 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.15 4x2 141 in 14,000 lbs 9,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x2 122 in 13,100 lbs 8,400 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x2 141 in 14,000 lbs 9,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x4 122 in 13,300 lbs 8,300 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x4 141 in 14,200 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x2 122 in 13,900 lbs 9,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x2 141 in 15,000 lbs 10,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x4 122 in 13,300 lbs 8,300 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x4 141 in 14,200 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x2 141 in 16,000 lbs 11,000 lbs Weight-distributing hitch + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.73 4x4 122 in 14,700 lbs 9,700 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x4 141 in 16,200 lbs 11,100 lbs Weight-distributing hitch + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.73 4x4 141 in 16,300 lbs 11,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
SuperCab
3.15 4x2 145 in 14,200 lbs 9,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.15 4x2 164 in 14,300 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x2 145 in 14,200 lbs 9,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x2 164 in 14,300 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x4 145 in 14,400 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x4 164 in 14,400 lbs 9,000 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x2 145 in 15,200 lbs 10,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x2 164 in 15,300 lbs 10,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x4 145 in 14,400 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x4 164 in 14,600 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x2 164 in 16,200 lbs 11,000 lbs Weight-distributing hitch + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.73 4x4 145 in 16,600 lbs 11,300 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x4 164 in 16,200 lbs 10,700 lbs Weight-distributing hitch + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.73 4x4 164 in 16,600 lbs 11,200 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
SuperCrew
3.15 4x2 145 in 14,200 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.15 4x2 157 in 14,200 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x2 145 in 14,200 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x2 157 in 14,200 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x4 145 in 14,400 lbs 9,000 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.31 4x4 157 in 14,400 lbs 9,000 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x2 145 in 15,200 lbs 10,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x2 157 in 15,200 lbs 10,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x4 145 in 14,500 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.55 4x4 157 in 14,500 lbs 9,100 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x2 157 in 16,300 lbs 10,900 lbs Weight-distributing hitch + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.73 4x4 145 in 16,300 lbs 10,900 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
3.73 4x4 157 in 16,300 lbs 10,700 lbs Weight-distributing hitch + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.18 p.18
3.73 4x4 157 in 16,900 lbs 11,500 lbs Weight-distributing hitch Section evidence · source-bound expansion · p.18 p.18
Towing Capacity Chart

5th-Wheel / Gooseneck Towing

Regular Cab
3.15 4x2 122 in 13,100 lbs 8,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.15 4x2 141 in 14,000 lbs 9,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x2 122 in 13,100 lbs 8,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x2 141 in 14,000 lbs 9,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x4 122 in 13,300 lbs 8,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x4 141 in 14,200 lbs 9,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x2 122 in 13,900 lbs 9,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x2 141 in 15,000 lbs 10,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x4 122 in 13,300 lbs 8,300 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x4 141 in 14,200 lbs 9,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x2 141 in 16,000 lbs 10,900 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.73 4x4 122 in 14,700 lbs 9,400 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x4 141 in 16,200 lbs 11,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.73 4x4 141 in 16,300 lbs 11,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
SuperCab
3.15 4x2 145 in 14,200 lbs 9,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.15 4x2 164 in 14,300 lbs 9,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x2 145 in 14,200 lbs 9,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x2 164 in 14,300 lbs 9,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x4 145 in 14,400 lbs 9,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x4 164 in 14,400 lbs 8,900 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x2 145 in 15,200 lbs 10,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x2 164 in 15,300 lbs 10,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x4 145 in 14,400 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x4 164 in 14,600 lbs 9,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x2 164 in 16,200 lbs 10,900 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.73 4x4 145 in 16,600 lbs 11,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x4 164 in 16,600 lbs 10,200 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x4 164 in 16,200 lbs 10,600 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
SuperCrew
3.15 4x2 145 in 14,200 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
3.15 4x2 157 in 14,200 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x2 145 in 14,200 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
3.31 4x2 157 in 14,200 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.31 4x4 145 in 14,400 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
3.31 4x4 157 in 14,400 lbs 8,900 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x2 145 in 15,200 lbs 10,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
3.55 4x2 157 in 15,200 lbs 10,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.55 4x4 145 in 14,500 lbs 9,100 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
3.55 4x4 157 in 14,500 lbs 9,000 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x2 157 in 16,300 lbs 10,900 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
3.73 4x4 145 in 16,300 lbs 10,500 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + 145 in SuperCrew 5.5 ft box: current 5th-wheel trailer designs do not fit Section evidence / Column evidence · source-bound expansion · p.20 p.20
3.73 4x4 157 in 16,900 lbs 10,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package Section evidence · source-bound expansion · p.20 p.20
3.73 4x4 157 in 16,300 lbs 10,700 lbs Trailer Tow Package (53A) or Max Trailer Tow Package + Heavy-Duty Payload Package + 18 in tires and wheels Section evidence / Row evidence · source-bound expansion / direct source · p.20 p.20
POWERTRAIN

Towing Capacity by Engine

Your engine determines your base towing limit and which max-tow packages are available. Start here to see the 2019 ratings for your specific truck setup.

Ford’s towing charts sometimes use technical engine labels. We show the familiar engine name first and Ford’s chart label alongside it so you can match both.

Highest Capacity
3.5L GTDI V6
Range: 6,000 - 13,200 lbs
Max conventional tow 13,200 LBS
3.0L Turbo Diesel V6
Range: 7,200 - 11,500 lbs
Max conventional tow 11,500 LBS
5.0L 4-Valve V8
Range: 8,300 - 11,500 lbs
Max conventional tow 11,500 LBS
2.7L GTDI V6
Range: 7,400 - 9,000 lbs
Max conventional tow 9,000 LBS
3.3L PFDI V6
Range: 5,000 - 7,700 lbs
Max conventional tow 7,700 LBS
Guide policy

Guide rules included

Trailers over 5,000 lbs require Trailer Tow Package or Max Trailer Tow Package. Other guide pages are cited below but are not converted into universal requirements for this year.

Rows

Chart labels stay specific

Requirement labels in the table come from Ford chart cells, section notes, and footnotes for the matching row.

Navigation

Trim pages stay separate

The 2019 trim shortcuts are not published here. Use year, engine, cab, drivetrain, axle, GCWR, and wheelbase filters to narrow the chart.

Technical Audit

Data sources

These citations show the Ford guide pages used to build the 2019 overview.

Show source pages for the 2019 guide
DOC_ID: ford-tow DOCUMENT BASIS

Ford RV & Trailer Towing Guide 2019

Audit Scope PAGES: 15-21, 26, 38, 41
PDF Creation Date 2018-11-28
Guide Revision Date 2018-10-25, 2018-11-13, 2018-11-26
