2017 Ram 1500 towing capacity.

Published towing ratings for the 2017 Ram 1500 run from 4,210 - 10,640 lbs depending on engine, cab, axle ratio, box length, drivetrain, and equipment.

Find your exact towing capacity Run the 2017 lookup tool → Check towing capacity by VIN Decode your VIN to prefill the 2017 lookup → View full comparison chart Jump to the full rating chart →

Retrieved from official Ram 2017 towing guide publications. Citations available below.

2017 Ram 1500
2017 TOWING RANGE
4,210 - 10,640 LBS
PEAK PAYLOAD
1,880 LBS
MAX GCWR
15,950 LBS
2017 Ram 1500 towing capacity chart
Engine Chart

3.0L V6 EcoDiesel

7,540 - 9,210 lbs Engine page →

CREW CAB - 5'7" Box, 4x2
3.92 6,950 lbs 1,530 lbs 14,750 lbs 8,860 lbs Base 5,416.51 lbs Base F/R 3,129.84 lbs / 2,286.67 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.4
3.55 6,950 lbs 1,530 lbs 13,750 lbs 7,860 lbs Base 5,416.51 lbs Base F/R 3,129.84 lbs / 2,286.67 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.4
3.92 6,950 lbs 1,530 lbs 13,750 lbs 7,860 lbs Base 5,416.51 lbs Base F/R 3,129.84 lbs / 2,286.67 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.4
CREW CAB - 5'7" Box, 4x4
3.92 6,950 lbs 1,320 lbs 14,750 lbs 8,580 lbs Base 5,630.55 lbs Base F/R 3,311.45 lbs / 2,319.1 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.4
3.55 6,950 lbs 1,320 lbs 13,750 lbs 7,580 lbs Base 5,630.55 lbs Base F/R 3,311.45 lbs / 2,319.1 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.4
3.92 6,950 lbs 1,320 lbs 13,750 lbs 7,580 lbs Base 5,630.55 lbs Base F/R 3,311.45 lbs / 2,319.1 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.4
CREW CAB - 6'4" Box, 4x4
3.92 6,950 lbs 1,250 lbs 14,550 lbs 8,340 lbs Base 5,695.01 lbs Base F/R 3,375.07 lbs / 2,319.94 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.5
3.55 6,950 lbs 1,250 lbs 13,750 lbs 7,540 lbs Base 5,695.01 lbs Base F/R 3,375.07 lbs / 2,319.94 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.5
3.92 6,950 lbs 1,250 lbs 13,750 lbs 7,540 lbs Base 5,695.01 lbs Base F/R 3,375.07 lbs / 2,319.94 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.5
QUAD CAB - 6'4" Box 4x2
3.92 6,950 lbs 1,590 lbs 14,750 lbs 8,960 lbs Base 5,356.82 lbs Base F/R 3,127.93 lbs / 2,228.89 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.3
3.55 6,950 lbs 1,590 lbs 13,750 lbs 7,960 lbs Base 5,356.82 lbs Base F/R 3,127.93 lbs / 2,228.89 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.3
3.92 6,950 lbs 1,590 lbs 13,750 lbs 7,960 lbs Base 5,356.82 lbs Base F/R 3,127.93 lbs / 2,228.89 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.3
QUAD CAB - 6'4" Box 4x2 - HFE
3.55 6,945 lbs 1,500 lbs 13,750 lbs 7,920 lbs Base 5,449.23 lbs Base F/R 3,107.11 lbs / 2,342.12 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 · HFE p.3
QUAD CAB - 6'4" Box 4x4
3.92 6,950 lbs 1,380 lbs 14,750 lbs 8,650 lbs Base 5,567.09 lbs Base F/R 3,304.47 lbs / 2,262.62 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.3
3.55 6,950 lbs 1,380 lbs 13,750 lbs 7,650 lbs Base 5,567.09 lbs Base F/R 3,304.47 lbs / 2,262.62 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.3
3.92 6,950 lbs 1,380 lbs 13,750 lbs 7,650 lbs Base 5,567.09 lbs Base F/R 3,304.47 lbs / 2,262.62 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.3
STD CAB - 8' Box, 4x2
3.92 6,600 lbs 1,510 lbs 14,750 lbs 9,210 lbs Base 5,094.87 lbs Base F/R 2,902.59 lbs / 2,192.28 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.2
3.55 6,600 lbs 1,510 lbs 13,750 lbs 8,240 lbs Base 5,094.87 lbs Base F/R 2,902.59 lbs / 2,192.28 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.2
3.92 6,600 lbs 1,510 lbs 13,750 lbs 8,240 lbs Base 5,094.87 lbs Base F/R 2,902.59 lbs / 2,192.28 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.2
STD CAB - 8' Box, 4x4
3.92 6,600 lbs 1,290 lbs 14,750 lbs 9,030 lbs Base 5,312.25 lbs Base F/R 3,203.56 lbs / 2,108.69 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.2
3.55 6,600 lbs 1,290 lbs 13,750 lbs 8,030 lbs Base 5,312.25 lbs Base F/R 3,203.56 lbs / 2,108.69 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.2
3.92 6,600 lbs 1,290 lbs 13,750 lbs 8,030 lbs Base 5,312.25 lbs Base F/R 3,203.56 lbs / 2,108.69 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.2
Engine Chart

3.6L V6

4,210 - 7,600 lbs Engine page →

CREW CAB - 5'7" Box, 4x2
3.55 6,800 lbs 1,820 lbs 12,900 lbs 7,510 lbs Base 4,980.14 lbs Base F/R 2,745.57 lbs / 2,234.57 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 845RE p.4
3.21 6,800 lbs 1,820 lbs 9,850 lbs 4,510 lbs Base 4,980.14 lbs Base F/R 2,745.57 lbs / 2,234.57 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 845RE p.4
CREW CAB - 5'7" Box, 4x4
3.55 6,800 lbs 1,630 lbs 12,900 lbs 7,210 lbs Base 5,170.5 lbs Base F/R 2,914.6 lbs / 2,255.9 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 845RE p.4
3.92 6,800 lbs 1,630 lbs 12,900 lbs 7,210 lbs Base 5,170.5 lbs Base F/R 2,914.6 lbs / 2,255.9 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 845RE p.4
3.21 6,800 lbs 1,630 lbs 9,850 lbs 4,210 lbs Base 5,170.5 lbs Base F/R 2,914.6 lbs / 2,255.9 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 845RE p.4
QUAD CAB - 6'4" Box 4x2
3.55 6,800 lbs 1,880 lbs 12,900 lbs 7,600 lbs Base 4,921.6 lbs Base F/R 2,740.99 lbs / 2,180.61 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 845RE p.3
3.21 6,800 lbs 1,880 lbs 9,850 lbs 4,610 lbs Base 4,921.6 lbs Base F/R 2,740.99 lbs / 2,180.61 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 845RE p.3
QUAD CAB - 6'4" Box 4x4
3.55 6,800 lbs 1,700 lbs 12,900 lbs 7,420 lbs Base 5,101.15 lbs Base F/R 2,903.82 lbs / 2,197.33 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 845RE p.3
3.21 6,800 lbs 1,700 lbs 9,850 lbs 4,430 lbs Base 5,101.15 lbs Base F/R 2,903.82 lbs / 2,197.33 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 845RE p.3
STD CAB - 6'4" Box, 4x2
3.55 6,025 lbs 1,500 lbs 12,200 lbs 7,260 lbs Base 4,523.9 lbs Base F/R 2,500.92 lbs / 2,022.98 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 845RE p.1
3.21 6,025 lbs 1,500 lbs 9,850 lbs 4,970 lbs Base 4,523.9 lbs Base F/R 2,500.92 lbs / 2,022.98 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 845RE p.1
STD CAB - 6'4" Box, 4x4
3.55 6,300 lbs 1,560 lbs 12,200 lbs 7,050 lbs Base 4,738.78 lbs Base F/R 2,678.75 lbs / 2,060.03 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 845RE p.1
3.21 6,300 lbs 1,560 lbs 9,850 lbs 4,750 lbs Base 4,738.78 lbs Base F/R 2,678.75 lbs / 2,060.03 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 845RE p.1
STD CAB - 8' Box, 4x2
3.55 6,600 lbs 1,880 lbs 12,400 lbs 7,270 lbs Base 4,718.49 lbs Base F/R 2,662.99 lbs / 2,055.5 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 845RE p.2
3.21 6,600 lbs 1,880 lbs 9,850 lbs 4,770 lbs Base 4,718.49 lbs Base F/R 2,662.99 lbs / 2,055.5 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 845RE p.2
STD CAB - 8' Box, 4x4
3.55 6,600 lbs 1,690 lbs 12,400 lbs 7,080 lbs Base 4,910.37 lbs Base F/R 2,869.41 lbs / 2,040.96 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 845RE p.2
3.21 6,600 lbs 1,690 lbs 9,850 lbs 4,580 lbs Base 4,910.37 lbs Base F/R 2,869.41 lbs / 2,040.96 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 845RE p.2
Engine Chart

5.7L V8 HEMI

5,030 - 10,640 lbs Engine page →

CREW CAB - 5'7" Box, 4x2
3.92 6,900 lbs 1,700 lbs 15,950 lbs 10,330 lbs Base 5,203.47 lbs Base F/R 2,963.13 lbs / 2,240.34 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.4
3.92 6,900 lbs 1,680 lbs 15,950 lbs 10,220 lbs Base 5,218.85 lbs Base F/R 2,977.38 lbs / 2,241.47 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.4
3.55 6,900 lbs 1,700 lbs 14,400 lbs 8,780 lbs Base 5,203.47 lbs Base F/R 2,963.13 lbs / 2,240.34 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.4
3.21 6,900 lbs 1,680 lbs 13,800 lbs 8,070 lbs Base 5,218.85 lbs Base F/R 2,977.38 lbs / 2,241.47 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.4
3.21 6,900 lbs 1,700 lbs 12,350 lbs 6,730 lbs Base 5,203.47 lbs Base F/R 2,963.13 lbs / 2,240.34 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.4
CREW CAB - 5'7" Box, 4x4
3.92 6,900 lbs 1,530 lbs 15,950 lbs 10,160 lbs Base 5,371.9 lbs Base F/R 3,122.08 lbs / 2,249.82 lbs GAWR F/R 3,900 lbs / 3,900 lbs A6 65RFE p.4
3.92 6,900 lbs 1,510 lbs 15,950 lbs 10,140 lbs Base 5,387.61 lbs Base F/R 3,141.9 lbs / 2,245.71 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.4
3.55 6,900 lbs 1,530 lbs 14,400 lbs 8,610 lbs Base 5,371.9 lbs Base F/R 3,122.08 lbs / 2,249.82 lbs GAWR F/R 3,900 lbs / 3,900 lbs A6 65RFE p.4
3.21 6,900 lbs 1,510 lbs 13,800 lbs 7,990 lbs Base 5,387.61 lbs Base F/R 3,141.9 lbs / 2,245.71 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.4
CREW CAB - 6'4" Box, 4x4
3.92 6,900 lbs 1,490 lbs 15,950 lbs 10,080 lbs Base 5,409.51 lbs Base F/R 3,124.96 lbs / 2,284.55 lbs GAWR F/R 3,900 lbs / 3,900 lbs A6 65RFE p.5
3.92 6,900 lbs 1,450 lbs 15,850 lbs 9,830 lbs Base 5,451.56 lbs Base F/R 3,223.72 lbs / 2,227.84 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.5
3.55 6,900 lbs 1,490 lbs 14,400 lbs 8,530 lbs Base 5,409.51 lbs Base F/R 3,124.96 lbs / 2,284.55 lbs GAWR F/R 3,900 lbs / 3,900 lbs A6 65RFE p.5
3.21 6,900 lbs 1,450 lbs 13,800 lbs 7,780 lbs Base 5,451.56 lbs Base F/R 3,223.72 lbs / 2,227.84 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.5
CREW CAB - 6'4" Box,4x2
3.92 6,900 lbs 1,680 lbs 15,950 lbs 10,310 lbs Base 5,217.68 lbs Base F/R 3,030.17 lbs / 2,187.51 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.5
3.92 6,900 lbs 1,640 lbs 15,950 lbs 10,200 lbs Base 5,260.35 lbs Base F/R 3,044.19 lbs / 2,216.16 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.5
3.55 6,900 lbs 1,680 lbs 14,400 lbs 8,760 lbs Base 5,217.68 lbs Base F/R 3,030.17 lbs / 2,187.51 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.5
3.21 6,900 lbs 1,640 lbs 13,800 lbs 8,050 lbs Base 5,260.35 lbs Base F/R 3,044.19 lbs / 2,216.16 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.5
3.21 6,900 lbs 1,680 lbs 12,350 lbs 6,710 lbs Base 5,217.68 lbs Base F/R 3,030.17 lbs / 2,187.51 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.5
QUAD CAB - 6'4" Box 4x2
3.92 6,900 lbs 1,790 lbs 15,950 lbs 10,420 lbs Base 5,107.12 lbs Base F/R 2,955.55 lbs / 2,151.57 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.3
3.92 6,900 lbs 1,760 lbs 15,950 lbs 10,340 lbs Base 5,144.9 lbs Base F/R 2,970.37 lbs / 2,174.53 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.3
3.55 6,900 lbs 1,790 lbs 14,400 lbs 8,870 lbs Base 5,107.12 lbs Base F/R 2,955.55 lbs / 2,151.57 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.3
3.21 6,900 lbs 1,760 lbs 13,800 lbs 8,190 lbs Base 5,144.9 lbs Base F/R 2,970.37 lbs / 2,174.53 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.3
3.21 6,900 lbs 1,790 lbs 12,350 lbs 6,820 lbs Base 5,107.12 lbs Base F/R 2,955.55 lbs / 2,151.57 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.3
QUAD CAB - 6'4" Box 4x4
3.92 6,900 lbs 1,580 lbs 15,950 lbs 10,220 lbs Base 5,320.33 lbs Base F/R 3,132.53 lbs / 2,187.8 lbs GAWR F/R 3,900 lbs / 3,900 lbs A6 65RFE p.3
3.92 6,900 lbs 1,570 lbs 15,950 lbs 10,150 lbs Base 5,328.37 lbs Base F/R 3,126.11 lbs / 2,202.26 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.3
3.55 6,900 lbs 1,580 lbs 14,400 lbs 8,670 lbs Base 5,320.33 lbs Base F/R 3,132.53 lbs / 2,187.8 lbs GAWR F/R 3,900 lbs / 3,900 lbs A6 65RFE p.3
3.21 6,900 lbs 1,570 lbs 13,800 lbs 8,000 lbs Base 5,328.37 lbs Base F/R 3,126.11 lbs / 2,202.26 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.3
STD CAB - 6'4" Box, 4x2
3.55 6,350 lbs 1,600 lbs 14,400 lbs 9,220 lbs Base 4,746.52 lbs Base F/R 2,725.5 lbs / 2,021.02 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.1
3.92 6,350 lbs 1,590 lbs 14,350 lbs 9,160 lbs Base 4,761.97 lbs Base F/R 2,736.07 lbs / 2,025.9 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.1
3.92 6,350 lbs 1,600 lbs 14,325 lbs 9,150 lbs Base 4,746.52 lbs Base F/R 2,725.5 lbs / 2,021.02 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.1
3.21 6,350 lbs 1,590 lbs 13,800 lbs 8,610 lbs Base 4,761.97 lbs Base F/R 2,736.07 lbs / 2,025.9 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.1
3.21 6,350 lbs 1,600 lbs 12,350 lbs 7,170 lbs Base 4,746.52 lbs Base F/R 2,725.5 lbs / 2,021.02 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.1
STD CAB - 6'4" Box, 4x2, R/T
3.92 6,200 lbs 1,350 lbs 10,250 lbs 5,030 lbs Base 4,847.76 lbs Base F/R 2,757.96 lbs / 2,089.8 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 · R/T p.1
STD CAB - 6'4" Box, 4x4
3.55 6,350 lbs 1,400 lbs 14,400 lbs 9,030 lbs Base 4,953.88 lbs Base F/R 2,896.22 lbs / 2,057.66 lbs GAWR F/R 3,900 lbs / 3,900 lbs A6 65RFE p.1
3.92 6,350 lbs 1,400 lbs 14,325 lbs 8,960 lbs Base 4,953.88 lbs Base F/R 2,896.22 lbs / 2,057.66 lbs GAWR F/R 3,900 lbs / 3,900 lbs A6 65RFE p.1
3.92 6,350 lbs 1,390 lbs 14,350 lbs 8,930 lbs Base 4,959.55 lbs Base F/R 2,895.57 lbs / 2,063.98 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.1
3.21 6,350 lbs 1,390 lbs 13,800 lbs 8,380 lbs Base 4,959.55 lbs Base F/R 2,895.57 lbs / 2,063.98 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.1
STD CAB - 8' Box, 4x2
3.92 6,600 lbs 1,700 lbs 15,950 lbs 10,640 lbs Base 4,895.56 lbs Base F/R 2,862.38 lbs / 2,033.18 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.2
3.92 6,600 lbs 1,690 lbs 15,950 lbs 10,620 lbs Base 4,914.87 lbs Base F/R 2,801.03 lbs / 2,113.84 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.2
3.55 6,600 lbs 1,700 lbs 14,400 lbs 9,090 lbs Base 4,895.56 lbs Base F/R 2,862.38 lbs / 2,033.18 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.2
3.21 6,600 lbs 1,690 lbs 13,800 lbs 8,470 lbs Base 4,914.87 lbs Base F/R 2,801.03 lbs / 2,113.84 lbs GAWR F/R 3,700 lbs / 3,900 lbs A8 8HP70 p.2
3.21 6,600 lbs 1,700 lbs 12,350 lbs 7,040 lbs Base 4,895.56 lbs Base F/R 2,862.38 lbs / 2,033.18 lbs GAWR F/R 3,700 lbs / 3,900 lbs A6 65RFE p.2
STD CAB - 8' Box, 4x4
3.92 6,600 lbs 1,480 lbs 15,950 lbs 10,410 lbs Base 5,121.93 lbs Base F/R 3,034.46 lbs / 2,087.47 lbs GAWR F/R 3,900 lbs / 3,900 lbs A6 65RFE p.2
3.92 6,600 lbs 1,480 lbs 15,950 lbs 10,410 lbs Base 5,117.21 lbs Base F/R 3,043.92 lbs / 2,073.29 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.2
3.55 6,600 lbs 1,480 lbs 14,400 lbs 8,860 lbs Base 5,121.93 lbs Base F/R 3,034.46 lbs / 2,087.47 lbs GAWR F/R 3,900 lbs / 3,900 lbs A6 65RFE p.2
3.21 6,600 lbs 1,480 lbs 13,800 lbs 8,260 lbs Base 5,117.21 lbs Base F/R 3,043.92 lbs / 2,073.29 lbs GAWR F/R 3,900 lbs / 3,900 lbs A8 8HP70 p.2
POWERTRAIN

Towing Capacity by Engine

Your engine determines your base towing limit. Start here to see the 2017 ratings for your specific Ram 1500 setup.

Highest Capacity
5.7L V8 HEMI
Range: 5,030 - 10,640 lbs
Max rating 10,640 LBS
3.0L V6 EcoDiesel
Range: 7,540 - 9,210 lbs
Max rating 9,210 LBS
3.6L V6
Range: 4,210 - 7,600 lbs
Max rating 7,600 LBS
GUIDE POLICY COVERAGE
PARTIAL
Passenger / options / tongue fields stay blank when the guide omits them.
PUBLISHED LOAD INPUTS PASSENGER / OPTIONS / TONGUE
300 / N/A / 10%
N/A means the reviewed guide notes omit that field.
PAYLOAD METHOD GUIDE FORMULA
Payload = GVWR – Base Weight.
Payload = GVWR – Base Weight. · Estimated values · Rounded to nearest 10 lbs · pounds
SOURCE GUIDE REFERENCE
p.1
2017 Ram 1500 Towing Guide
VIEW PARTIAL GUIDE NOTES
PARTIAL GUIDE POLICY

Ground rules behind every 2017 Ram 1500 towing number.

These are the source-backed guide notes Ram actually prints for the Ram 1500 family in 2017.

FIG. 2017 LOAD Published Assumptions

Load assumptions the guide explicitly prints

  • Passenger weight: 300 lbs counted for driver and passengers.
  • Conventional tongue weight: 10% of gross trailer weight.
FIG. 2017 CALC Payload Formula

How Ram derives payload from base weight

  • Formula: Payload = GVWR – Base Weight.
  • Values: Published as estimated (not guaranteed).
  • Units: pounds
  • Rounding: nearest 10 lbs.
FIG. 2017 STD Standards + Limits

SAE J2807 guidance

  • Trailer Weight Rating and Tow Vehicle Trailering Weight are calculated as specified in SAE J2807. p.1
  • Class IV receiver max tongue weight: 1,100 lbs. p.1
  • Weight-distributing hitch recommended for trailers over 5,000 lbs. p.1
  • Quad Cab and Crew Cab models with Off Road Tire (s/c TXN), All Terrain Tire (s/c TWG) or Steel Wheel (s/c WFP) have 6800 lb GVWR. p.1
  • All models with 22 inch Tires (s/c TY4) have 6200 lb GVWR. p.1
  • Big Horn and Lone Star packages equipped with the 3.0L V6 EcoDiesel Engine and a 3.92 axle ratio have 13,750 lb. GCWR. p.1
FIG. 2017 WARN Warnings

Manufacturer safety warnings

  • Payload and Trailer Weight Rating are mutually exclusive.
  • GAWRs, GVWRs and GCWRs should never be exceeded.
FIG. 2017 NOTES Policy Notes

All published notes from the 2017 towing guide

  • Payload and Max Trailer Weights are ESTIMATED values. p.1
  • All weights are shown in pounds unless otherwise stated. p.1
  • Payload and Max Trailer Weight values are rounded to the nearest 10 lb. p.1
  • Payload = GVWR – Base Weight. p.1
  • Trailer Weight Rating and Tow Vehicle Trailering Weight are calculated as specified in SAE J2807. p.1
  • Passenger Weight = 300 lb. p.1
  • Options Weight is option content above 33 percent of sales volume. p.1
  • Trailer equipment weight = Class IV receiver hitch is 11.1 lb (if not already included in options weight). Trailer Hitch is 10 lb if TWR is less or equal to 5,000 lb and 65 lb if TWR is greater than 5,000 lb. p.1
  • Payload and Trailer Weight Rating are mutually exclusive. p.1
  • GAWRs, GVWRs and GCWRs should never be exceeded. p.1
  • The recommended tongue weight for a conventional hitch is 10 percent of the gross trailer weight. The maximum tongue weight for Class IV receiver hitch is limited to 1100 lb. p.1
  • Weight Distributing Hitch is recommended for trailers over 5,000 lb. p.1
  • Quad Cab and Crew Cab models with Off Road Tire (s/c TXN), All Terrain Tire (s/c TWG) or Steel Wheel (s/c WFP) have 6800 lb GVWR. p.1
  • All models with 22 inch Tires (s/c TY4) have 6200 lb GVWR. p.1
  • Big Horn and Lone Star packages equipped with the 3.0L V6 EcoDiesel Engine and a 3.92 axle ratio have 13,750 lb. GCWR. p.1
NOTES: This strip shows only the guide-wide assumptions, warnings, standards, and availability limits Ram explicitly prints for this family. Missing fields stay blank instead of being inferred.
Technical Audit

Data sources

These citations show the Ram guide pages used to build the 2017 overview.

Show source pages for the 2017 guide
DOC_ID: ram-1500 DOCUMENT BASIS

2017 Ram 1500 Towing Guide

Audit Scope PAGES: 1-5
PDF Creation Date 2016-06-28
