2025 Ram 1500 towing capacity.

Published towing ratings for the 2025 Ram 1500 run from 6,330 - 11,580 lbs depending on engine, cab, axle ratio, box length, drivetrain, and equipment.

Find your exact towing capacity Run the 2025 lookup tool → Check towing capacity by VIN Decode your VIN to prefill the 2025 lookup → View full comparison chart Jump to the full rating chart →

Retrieved from official Ram 2025 towing guide publications. Citations available below.

2025 Ram 1500
2025 TOWING RANGE
6,330 - 11,580 LBS
PEAK PAYLOAD
2,370 LBS
MAX GCWR
17,000 LBS
2025 Ram 1500 towing capacity chart
Engine Chart

3.0L I6 HO Twin Turbo w/ESS

8,380 - 9,880 lbs

RAM 1500 4X4 CREW LIMITED 5'7" BOX
3.92 7,100 lbs 1,340 lbs 15,873 lbs 9,340 lbs Base 5,756 lbs Base F/R 3,259 lbs / 2,497 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Limited p.3
RAM 1500 4X4 CREW LIMITED 6'4" BOX
3.92 7,100 lbs 1,380 lbs 16,134 lbs 9,880 lbs Base 5,724 lbs Base F/R 3,335 lbs / 2,388 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Limited p.2
RAM 1500 4X4 CREW RHO 5'7" BOX
3.92 7,800 lbs 1,520 lbs 15,160 lbs 8,380 lbs Base 6,283 lbs Base F/R 3,505 lbs / 2,778 lbs GAWR F/R 4,300 lbs / 4,200 lbs 8-Spd Auto 8HP75 · RHO p.3
Engine Chart

3.0L I6 Twin Turbo w/ESS

8,050 - 11,580 lbs Engine page →

RAM 1500 4X2 CREW TRADESMAN 5'7" BOX
3.92 6,900 lbs 1,850 lbs 17,000 lbs 11,580 lbs Base 5,052 lbs Base F/R 2,932 lbs / 2,119 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.1
3.21 6,900 lbs 1,850 lbs 13,900 lbs 8,480 lbs Base 5,052 lbs Base F/R 2,932 lbs / 2,119 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.1
RAM 1500 4X2 CREW TRADESMAN 6'4" BOX
3.92 6,900 lbs 1,770 lbs 17,000 lbs 11,430 lbs Base 5,134 lbs Base F/R 3,018 lbs / 2,115 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.1
3.21 6,900 lbs 1,770 lbs 13,900 lbs 8,330 lbs Base 5,134 lbs Base F/R 3,018 lbs / 2,115 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.1
RAM 1500 4X2 QUAD HFE 6'4" BOX
3.21 6,875 lbs 1,820 lbs 13,900 lbs 8,480 lbs Base 5,054 lbs Base F/R 2,941 lbs / 2,112 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 8HP75 · HFE p.1
RAM 1500 4X2 QUAD TRADESMAN 6'4" BOX
3.92 6,900 lbs 1,870 lbs 17,000 lbs 11,540 lbs Base 5,033 lbs Base F/R 2,919 lbs / 2,113 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.1
3.21 6,900 lbs 1,870 lbs 13,900 lbs 8,440 lbs Base 5,033 lbs Base F/R 2,919 lbs / 2,113 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.1
RAM 1500 4X4 CREW TRADESMAN 5'7" BOX
3.92 7,100 lbs 1,840 lbs 17,000 lbs 11,300 lbs Base 5,210 lbs Base F/R 3,081 lbs / 2,129 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.2
3.55 7,100 lbs 1,840 lbs 13,900 lbs 8,200 lbs Base 5,210 lbs Base F/R 3,081 lbs / 2,129 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.2
RAM 1500 4X4 CREW TRADESMAN 6'4" BOX
3.92 7,100 lbs 1,730 lbs 17,000 lbs 11,150 lbs Base 5,368 lbs Base F/R 3,191 lbs / 2,176 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.2
3.55 7,100 lbs 1,730 lbs 13,900 lbs 8,050 lbs Base 5,368 lbs Base F/R 3,191 lbs / 2,176 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.2
RAM 1500 4X4 QUAD TRADESMAN 6'4" BOX
3.92 7,100 lbs 1,980 lbs 17,000 lbs 11,460 lbs Base 5,119 lbs Base F/R 3,074 lbs / 2,045 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.2
3.55 7,100 lbs 1,980 lbs 13,900 lbs 8,360 lbs Base 5,119 lbs Base F/R 3,074 lbs / 2,045 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 8HP75 · Tradesman p.2
Engine Chart

3.6L V6 24V VVT BSG

6,330 - 8,120 lbs Engine page →

RAM 1500 4X2 CREW TRADESMAN 5'7" BOX
3.55 6,900 lbs 1,980 lbs 12,900 lbs 7,610 lbs Base 4,920 lbs Base F/R 2,764 lbs / 2,156 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 850RE · Tradesman p.1
3.21 6,900 lbs 1,980 lbs 11,900 lbs 6,610 lbs Base 4,920 lbs Base F/R 2,764 lbs / 2,156 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 850RE · Tradesman p.1
RAM 1500 4X2 QUAD HFE 6'4" BOX
3.21 6,010 lbs 1,190 lbs 11,900 lbs 6,720 lbs Base 4,820 lbs Base F/R 2,729 lbs / 2,090 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 850RE · HFE p.1
RAM 1500 4X2 QUAD TRADESMAN 6'4" BOX
3.55 7,200 lbs 2,370 lbs 13,370 lbs 8,120 lbs Base 4,829 lbs Base F/R 2,755 lbs / 2,073 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 850RE · Tradesman p.1
3.55 7,200 lbs 2,370 lbs 12,900 lbs 7,650 lbs Base 4,829 lbs Base F/R 2,755 lbs / 2,073 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8-Spd Auto 850RE · Tradesman p.1
RAM 1500 4X4 CREW TRADESMAN 5'7" BOX
3.55 6,900 lbs 1,800 lbs 12,900 lbs 7,330 lbs Base 5,118 lbs Base F/R 2,934 lbs / 2,183 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 850RE · Tradesman p.2
3.21 6,900 lbs 1,800 lbs 11,900 lbs 6,330 lbs Base 5,118 lbs Base F/R 2,934 lbs / 2,183 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 850RE · Tradesman p.2
RAM 1500 4X4 QUAD TRADESMAN 6'4" BOX
3.55 6,800 lbs 1,810 lbs 12,900 lbs 7,490 lbs Base 4,989 lbs Base F/R 2,911 lbs / 2,077 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 850RE · Tradesman p.2
3.21 6,800 lbs 1,810 lbs 11,900 lbs 6,490 lbs Base 4,989 lbs Base F/R 2,911 lbs / 2,077 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8-Spd Auto 850RE · Tradesman p.2
POWERTRAIN

Towing Capacity by Engine

Your engine determines your base towing limit. Start here to see the 2025 ratings for your specific Ram 1500 setup.

Highest Capacity
3.0L I6 Twin Turbo w/ESS
Range: 8,050 - 11,580 lbs
Max rating 11,580 LBS
3.0L I6 HO Twin Turbo w/ESS
Range: 8,380 - 9,880 lbs
Max rating 9,880 LBS
3.6L V6 24V VVT BSG
Range: 6,330 - 8,120 lbs
Max rating 8,120 LBS
LOADING ASSUMPTIONS TONGUE WEIGHT
10% OF TRAILER
Conventional hitch
OCCUPANT + OPTIONS DEDUCTIONS
400 LBS
300 passenger + 100 options
RATING METHOD STANDARD
SAE J2807
Industry tow rating standard
SOURCE GUIDE REFERENCE
p.3
2025 Ram 1500 Towing Guide
VIEW ALL FINE PRINT
GUIDE FINE PRINT

Ground rules behind every 2025 Ram 1500 towing number.

These ground rules define how Ram calculates every 2025 payload and towing number on this page.

FIG. 2025 LOAD Published Assumptions

Weights Ram already counted in every number

  • Passenger weight: 300 lbs counted for driver and passengers.
  • Options weight: 100 lbs counted for factory-installed options.
  • Conventional tongue weight: 10% of gross trailer weight.
FIG. 2025 CALC Payload Formula

How Ram derives payload from base weight

  • Formula: Payload = GVWR - Base Weight
  • Values: Published as estimated (not guaranteed).
  • Units: pounds
  • Rounding: nearest 10 lbs.
FIG. 2025 STD Rating Standard

SAE J2807 guidance

  • Trailer Weight Rating and Tow Vehicle Trailering Weight are calculated as specified in SAE J2807. p.3
FIG. 2025 WARN Warnings

Manufacturer safety warnings

  • Payload and Trailer Weight Rating are mutually exclusive.
  • GAWRs, GVWRs and GCWRs should never be exceeded.
  • Payload and GAWR should never be exceeded and must account for all of the above weights, including the appropriate trailering equipment and tongue weight.
FIG. 2025 NOTES Policy Notes

All published notes from the 2025 towing guide

  • Payload and Max Trailer Weights are ESTIMATED values. p.3
  • All values are shown in pounds unless otherwise stated. p.3
  • Payload and Max Trailer Weight values are rounded to the nearest 10 lbs. p.3
  • Payload = GVWR - Base Weight p.3
  • Payload and Trailer Weight Rating are mutually exclusive. p.3
  • GAWRs, GVWRs and GCWRs should never be exceeded. p.3
  • Trailer Weight Rating and Tow Vehicle Trailering Weight are calculated as specified in SAE J2807. p.3
  • Passenger Weight = 300 lbs. p.3
  • Options Weight = 100 lbs. p.3
  • Tongue weight: 10 percent of the gross trailer weight for Conventional Hitch. p.3
  • Payload and GAWR should never be exceeded and must account for all of the above weights, including the appropriate trailering equipment and tongue weight. p.3
NOTES: These ground rules apply to every published towing and payload value. Your specific truck configuration may have additional constraints.
Technical Audit

Data sources

These citations show the Ram guide pages used to build the 2025 overview.

Show source pages for the 2025 guide
DOC_ID: ram-1500 DOCUMENT BASIS

2025 Ram 1500 Towing Guide

Audit Scope PAGES: 1-3
PDF Creation Date 2024-05-30
