2019 Ram 1500 towing capacity.

Published towing ratings for the 2019 Ram 1500 run from 4,390 - 12,750 lbs depending on engine, cab, axle ratio, box length, drivetrain, and equipment.

Find your exact towing capacity Run the 2019 lookup tool → Check towing capacity by VIN Decode your VIN to prefill the 2019 lookup → View full comparison chart Jump to the full rating chart →

Retrieved from official Ram 2019 towing guide publications. Citations available below.

2019 Ram 1500
2019 TOWING RANGE
4,390 - 12,750 LBS
PEAK PAYLOAD
2,300 LBS
MAX GCWR
18,200 LBS
2019 Ram 1500 towing capacity chart

Ram 1500 Classic

3 engines · 4,390 - 10,710 lbs · Peak payload 1,920 lbs

View Ram 1500 engines ↓ Back to chart top ↑
Engine Chart

3.0L V6 Turbo Diesel

7,680 - 9,260 lbs Engine page →

RAM 1500 4X2 CREW ST 5'7" BOX (Body Style DS1L98)
3.92 6,800 lbs 1,420 lbs 14,750 lbs 9,010 lbs Base 5,375 lbs Base F/R 3,114 lbs / 2,261 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.5
3.92 6,950 lbs 1,570 lbs 14,750 lbs 8,960 lbs Base 5,375 lbs Base F/R 3,114 lbs / 2,261 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.5
3.55 6,800 lbs 1,420 lbs 13,750 lbs 8,010 lbs Base 5,375 lbs Base F/R 3,114 lbs / 2,261 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.5
3.55 6,950 lbs 1,570 lbs 13,750 lbs 7,960 lbs Base 5,375 lbs Base F/R 3,114 lbs / 2,261 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.5
RAM 1500 4X2 CREW ST 6'4" BOX (Body Style DS1L91)
3.92 6,800 lbs 1,360 lbs 14,750 lbs 8,940 lbs Base 5,442 lbs Base F/R 3,103 lbs / 2,338 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.4
3.92 6,950 lbs 1,510 lbs 14,750 lbs 8,940 lbs Base 5,442 lbs Base F/R 3,103 lbs / 2,338 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.4
3.55 6,800 lbs 1,360 lbs 13,750 lbs 7,940 lbs Base 5,442 lbs Base F/R 3,103 lbs / 2,338 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.4
3.55 6,950 lbs 1,510 lbs 13,750 lbs 7,940 lbs Base 5,442 lbs Base F/R 3,103 lbs / 2,338 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.4
RAM 1500 4X2 QUAD ST 6'4" BOX
3.92 6,800 lbs 1,490 lbs 14,750 lbs 9,070 lbs Base 5,315 lbs Base F/R 3,107 lbs / 2,208 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.1
3.92 6,950 lbs 1,640 lbs 14,750 lbs 9,040 lbs Base 5,315 lbs Base F/R 3,107 lbs / 2,208 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.1
3.55 6,800 lbs 1,490 lbs 13,750 lbs 8,070 lbs Base 5,315 lbs Base F/R 3,107 lbs / 2,208 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.1
3.55 6,950 lbs 1,640 lbs 13,750 lbs 8,040 lbs Base 5,315 lbs Base F/R 3,107 lbs / 2,208 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.1
RAM 1500 4X2 REG ST 8' BOX (Body Style DS1L62)
3.92 6,600 lbs 1,510 lbs 14,750 lbs 9,260 lbs Base 5,088 lbs Base F/R 3,021 lbs / 2,067 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.3
3.55 6,600 lbs 1,510 lbs 13,750 lbs 8,260 lbs Base 5,088 lbs Base F/R 3,021 lbs / 2,067 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.3
RAM 1500 4X4 CREW ST 5'7" BOX (Body Style DS6L98)
3.92 6,800 lbs 1,190 lbs 14,750 lbs 8,770 lbs Base 5,614 lbs Base F/R 3,330 lbs / 2,285 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.10
3.92 6,950 lbs 1,340 lbs 14,750 lbs 8,750 lbs Base 5,614 lbs Base F/R 3,330 lbs / 2,285 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.10
3.55 6,800 lbs 1,190 lbs 13,750 lbs 7,770 lbs Base 5,614 lbs Base F/R 3,330 lbs / 2,285 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.10
3.55 6,950 lbs 1,340 lbs 13,750 lbs 7,750 lbs Base 5,614 lbs Base F/R 3,330 lbs / 2,285 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.10
RAM 1500 4X4 CREW ST 6'4" BOX (Body Style DS6L91)
3.92 6,800 lbs 1,140 lbs 14,550 lbs 8,530 lbs Base 5,658 lbs Base F/R 3,361 lbs / 2,297 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.9
3.92 6,950 lbs 1,290 lbs 14,550 lbs 8,480 lbs Base 5,658 lbs Base F/R 3,361 lbs / 2,297 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.9
3.55 6,800 lbs 1,140 lbs 13,750 lbs 7,730 lbs Base 5,658 lbs Base F/R 3,361 lbs / 2,297 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.9
3.55 6,950 lbs 1,290 lbs 13,750 lbs 7,680 lbs Base 5,658 lbs Base F/R 3,361 lbs / 2,297 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.9
RAM 1500 4X4 QUAD ST 6'4" BOX (Body Style DS6L41)
3.92 6,800 lbs 1,260 lbs 14,750 lbs 8,840 lbs Base 5,542 lbs Base F/R 3,278 lbs / 2,263 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.6
3.92 6,950 lbs 1,410 lbs 14,750 lbs 8,810 lbs Base 5,542 lbs Base F/R 3,278 lbs / 2,263 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.6
3.55 6,800 lbs 1,260 lbs 13,750 lbs 7,840 lbs Base 5,542 lbs Base F/R 3,278 lbs / 2,263 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.6
3.55 6,950 lbs 1,410 lbs 13,750 lbs 7,810 lbs Base 5,542 lbs Base F/R 3,278 lbs / 2,263 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.6
RAM 1500 4X4 REG ST 8' BOX (Body Style DS6L62)
3.92 6,600 lbs 1,300 lbs 14,750 lbs 9,040 lbs Base 5,305 lbs Base F/R 3,196 lbs / 2,109 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.8
3.55 6,600 lbs 1,300 lbs 13,750 lbs 8,040 lbs Base 5,305 lbs Base F/R 3,196 lbs / 2,109 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.8
Engine Chart

3.6L V6 Gas

4,390 - 7,680 lbs Engine page →

RAM 1500 4X2 CREW ST 5'7" BOX (Body Style DS1L98)
3.55 6,800 lbs 1,860 lbs 12,900 lbs 7,640 lbs Base 4,941 lbs Base F/R 2,722 lbs / 2,219 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.5
3.21 6,800 lbs 1,860 lbs 9,850 lbs 4,590 lbs Base 4,941 lbs Base F/R 2,722 lbs / 2,219 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.5
RAM 1500 4X2 QUAD ST 6'4" BOX
3.55 6,800 lbs 1,920 lbs 12,900 lbs 7,680 lbs Base 4,877 lbs Base F/R 2,719 lbs / 2,158 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.1
3.21 6,800 lbs 1,920 lbs 9,850 lbs 4,630 lbs Base 4,877 lbs Base F/R 2,719 lbs / 2,158 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.1
RAM 1500 4X2 REG ST 6'4" BOX (Body Style DS1L61)
3.55 6,025 lbs 1,500 lbs 12,200 lbs 7,360 lbs Base 4,520 lbs Base F/R 2,494 lbs / 2,026 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.2
3.21 6,025 lbs 1,500 lbs 9,850 lbs 5,010 lbs Base 4,520 lbs Base F/R 2,494 lbs / 2,026 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.2
RAM 1500 4X2 REG ST 8' BOX (Body Style DS1L62)
3.55 6,600 lbs 1,890 lbs 12,400 lbs 7,340 lbs Base 4,707 lbs Base F/R 2,656 lbs / 2,051 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.3
3.21 6,600 lbs 1,890 lbs 9,850 lbs 4,790 lbs Base 4,707 lbs Base F/R 2,656 lbs / 2,051 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.3
RAM 1500 4X4 CREW ST 5'7" BOX (Body Style DS6L98)
3.55 6,800 lbs 1,670 lbs 12,900 lbs 7,440 lbs Base 5,135 lbs Base F/R 2,889 lbs / 2,246 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.10
3.21 6,800 lbs 1,670 lbs 9,850 lbs 4,390 lbs Base 5,135 lbs Base F/R 2,889 lbs / 2,246 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.10
RAM 1500 4X4 QUAD ST 6'4" BOX (Body Style DS6L41)
3.55 6,800 lbs 1,740 lbs 12,900 lbs 7,490 lbs Base 5,060 lbs Base F/R 2,876 lbs / 2,184 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.6
3.21 6,800 lbs 1,740 lbs 9,850 lbs 4,440 lbs Base 5,060 lbs Base F/R 2,876 lbs / 2,184 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.6
RAM 1500 4X4 REG ST 6'4" BOX (Body Style DS6L61)
3.55 6,300 lbs 1,580 lbs 12,200 lbs 7,160 lbs Base 4,722 lbs Base F/R 2,655 lbs / 2,067 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.7
3.21 6,300 lbs 1,580 lbs 9,850 lbs 4,810 lbs Base 4,722 lbs Base F/R 2,655 lbs / 2,067 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.6
RAM 1500 4X4 REG ST 8' BOX (Body Style DS6L62)
3.55 6,600 lbs 1,710 lbs 12,400 lbs 7,140 lbs Base 4,892 lbs Base F/R 2,814 lbs / 2,078 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.8
3.21 6,600 lbs 1,710 lbs 9,850 lbs 4,590 lbs Base 4,892 lbs Base F/R 2,814 lbs / 2,078 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 845RE · ST p.8
Engine Chart

5.7L V8 Hemi MDS Gas

6,490 - 10,710 lbs Engine page →

RAM 1500 4X2 CREW ST 5'7" BOX (Body Style DS1L98)
3.92 6,800 lbs 1,620 lbs 15,975 lbs 10,430 lbs Base 5,184 lbs Base F/R 2,951 lbs / 2,233 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.5 Exact
3.92 6,900 lbs 1,720 lbs 15,975 lbs 10,410 to 10,420 lbs Base 5,184 lbs Base F/R 2,951 lbs / 2,233 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.5 Published range
3.92 6,800 lbs 1,600 lbs 15,950 lbs 10,390 lbs Base 5,200 lbs Base F/R 2,964 lbs / 2,236 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.5 Exact
3.92 6,900 lbs 1,700 lbs 15,950 lbs 10,370 to 10,380 lbs Base 5,200 lbs Base F/R 2,964 lbs / 2,236 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.5 Published range
3.55 6,800 lbs 1,600 lbs 14,400 lbs 8,840 lbs Base 5,200 lbs Base F/R 2,964 lbs / 2,236 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.5 Exact
3.55 6,900 lbs 1,700 lbs 14,400 lbs 8,820 to 8,830 lbs Base 5,200 lbs Base F/R 2,964 lbs / 2,236 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.5 Published range
3.21 6,800 lbs 1,620 lbs 13,800 lbs 8,250 lbs Base 5,184 lbs Base F/R 2,951 lbs / 2,233 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.5 Exact
3.21 6,900 lbs 1,720 lbs 13,800 lbs 8,230 to 8,240 lbs Base 5,184 lbs Base F/R 2,951 lbs / 2,233 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.5 Published range
3.21 6,800 lbs 1,600 lbs 12,350 lbs 6,790 lbs Base 5,200 lbs Base F/R 2,964 lbs / 2,236 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.5 Exact
3.21 6,900 lbs 1,700 lbs 12,350 lbs 6,770 to 6,780 lbs Base 5,200 lbs Base F/R 2,964 lbs / 2,236 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.5 Published range
RAM 1500 4X2 CREW ST 6'4" BOX (Body Style DS1L91)
3.92 6,800 lbs 1,590 lbs 15,975 lbs 10,400 lbs Base 5,206 lbs Base F/R 3,019 lbs / 2,187 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.4 Exact
3.92 6,800 lbs 1,580 lbs 15,950 lbs 10,360 lbs Base 5,222 lbs Base F/R 3,031 lbs / 2,190 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.4 Exact
3.92 6,900 lbs 1,690 lbs 15,975 lbs 10,360 lbs Base 5,206 lbs Base F/R 3,019 lbs / 2,187 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.4 Exact
3.92 6,900 lbs 1,680 lbs 15,950 lbs 10,320 lbs Base 5,222 lbs Base F/R 3,031 lbs / 2,190 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.4 Exact
3.55 6,800 lbs 1,580 lbs 14,400 lbs 8,810 lbs Base 5,222 lbs Base F/R 3,031 lbs / 2,190 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.4 Exact
3.55 6,900 lbs 1,680 lbs 14,400 lbs 8,770 lbs Base 5,222 lbs Base F/R 3,031 lbs / 2,190 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.4 Exact
3.21 6,800 lbs 1,590 lbs 13,800 lbs 8,230 lbs Base 5,206 lbs Base F/R 3,019 lbs / 2,187 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.4 Exact
3.21 6,900 lbs 1,690 lbs 13,800 lbs 8,180 lbs Base 5,206 lbs Base F/R 3,019 lbs / 2,187 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.4 Exact
3.21 6,800 lbs 1,580 lbs 12,350 lbs 6,760 lbs Base 5,222 lbs Base F/R 3,031 lbs / 2,190 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.4 Exact
3.21 6,900 lbs 1,680 lbs 12,350 lbs 6,720 lbs Base 5,222 lbs Base F/R 3,031 lbs / 2,190 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.4 Exact
RAM 1500 4X2 QUAD ST 6'4" BOX
3.92 6,800 lbs 1,700 lbs 15,975 lbs 10,510 lbs Base 5,095 lbs Base F/R 2,945 lbs / 2,151 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.1 Exact
3.92 6,800 lbs 1,690 lbs 15,950 lbs 10,470 lbs Base 5,111 lbs Base F/R 2,957 lbs / 2,154 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.1 Exact
3.92 6,900 lbs 1,800 lbs 15,975 lbs 10,470 to 10,510 lbs Base 5,095 lbs Base F/R 2,945 lbs / 2,151 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.1 Published range
3.92 6,900 lbs 1,790 lbs 15,950 lbs 10,430 to 10,470 lbs Base 5,111 lbs Base F/R 2,957 lbs / 2,154 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.1 Published range
3.55 6,800 lbs 1,690 lbs 14,400 lbs 8,920 lbs Base 5,111 lbs Base F/R 2,957 lbs / 2,154 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.1 Exact
3.55 6,900 lbs 1,790 lbs 14,400 lbs 8,880 to 8,920 lbs Base 5,111 lbs Base F/R 2,957 lbs / 2,154 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.1 Published range
3.21 6,800 lbs 1,700 lbs 13,800 lbs 8,340 lbs Base 5,095 lbs Base F/R 2,945 lbs / 2,151 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.1 Exact
3.21 6,900 lbs 1,800 lbs 13,800 lbs 8,290 to 8,340 lbs Base 5,095 lbs Base F/R 2,945 lbs / 2,151 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.1 Published range
3.21 6,800 lbs 1,690 lbs 12,350 lbs 6,870 lbs Base 5,111 lbs Base F/R 2,957 lbs / 2,154 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.1 Exact
3.21 6,900 lbs 1,790 lbs 12,350 lbs 6,830 to 6,870 lbs Base 5,111 lbs Base F/R 2,957 lbs / 2,154 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.1 Published range
RAM 1500 4X2 REG ST 6'4" BOX (Body Style DS1L61)
3.55 6,350 lbs 1,600 lbs 14,400 lbs 9,280 to 9,290 lbs Base 4,746 lbs Base F/R 2,717 lbs / 2,029 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.2 Published range
3.92 6,350 lbs 1,620 lbs 14,350 lbs 9,250 lbs Base 4,730 lbs Base F/R 2,705 lbs / 2,026 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.2 Exact
3.92 6,350 lbs 1,600 lbs 14,325 lbs 9,210 lbs Base 4,746 lbs Base F/R 2,717 lbs / 2,029 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.2 Exact
3.21 6,350 lbs 1,620 lbs 13,800 lbs 8,700 lbs Base 4,730 lbs Base F/R 2,705 lbs / 2,026 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.2 Exact
3.21 6,350 lbs 1,600 lbs 12,350 lbs 7,230 to 7,240 lbs Base 4,746 lbs Base F/R 2,717 lbs / 2,029 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.2 Published range
RAM 1500 4X2 REG ST 8' BOX (Body Style DS1L62)
3.92 6,600 lbs 1,700 lbs 15,975 lbs 10,710 lbs Base 4,897 lbs Base F/R 2,854 lbs / 2,043 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.3 Exact
3.92 6,600 lbs 1,690 lbs 15,950 lbs 10,670 lbs Base 4,913 lbs Base F/R 2,866 lbs / 2,047 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.3 Exact
3.55 6,600 lbs 1,690 lbs 14,400 lbs 9,120 lbs Base 4,913 lbs Base F/R 2,866 lbs / 2,047 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.3 Exact
3.21 6,600 lbs 1,700 lbs 13,800 lbs 8,530 to 8,540 lbs Base 4,897 lbs Base F/R 2,854 lbs / 2,043 lbs GAWR F/R 3,700 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.3 Published range
3.21 6,600 lbs 1,690 lbs 12,350 lbs 7,070 lbs Base 4,913 lbs Base F/R 2,866 lbs / 2,047 lbs GAWR F/R 3,700 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.3 Exact
RAM 1500 4X4 CREW ST 5'7" BOX (Body Style DS6L98)
3.92 6,800 lbs 1,430 lbs 15,975 lbs 10,240 lbs Base 5,369 lbs Base F/R 3,105 lbs / 2,264 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.10 Exact
3.92 6,900 lbs 1,530 lbs 15,975 lbs 10,220 lbs Base 5,369 lbs Base F/R 3,105 lbs / 2,264 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.10 Exact
3.92 6,800 lbs 1,420 lbs 15,950 lbs 10,200 lbs Base 5,385 lbs Base F/R 3,117 lbs / 2,267 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.10 Exact
3.92 6,900 lbs 1,520 lbs 15,950 lbs 10,180 lbs Base 5,385 lbs Base F/R 3,117 lbs / 2,267 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.10 Exact
3.55 6,800 lbs 1,420 lbs 14,400 lbs 8,650 lbs Base 5,385 lbs Base F/R 3,117 lbs / 2,267 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.10 Exact
3.55 6,900 lbs 1,520 lbs 14,400 lbs 8,630 lbs Base 5,385 lbs Base F/R 3,117 lbs / 2,267 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.10 Exact
3.21 6,800 lbs 1,430 lbs 13,800 lbs 8,070 lbs Base 5,369 lbs Base F/R 3,105 lbs / 2,264 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.10 Exact
3.21 6,900 lbs 1,530 lbs 13,800 lbs 8,050 lbs Base 5,369 lbs Base F/R 3,105 lbs / 2,264 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.10 Exact
3.21 6,800 lbs 1,420 lbs 12,350 lbs 6,600 lbs Base 5,385 lbs Base F/R 3,117 lbs / 2,267 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.10 Exact
3.21 6,900 lbs 1,520 lbs 12,350 lbs 6,580 lbs Base 5,385 lbs Base F/R 3,117 lbs / 2,267 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.10 Exact
RAM 1500 4X4 CREW ST 6'4" BOX (Body Style DS6L91)
3.92 6,800 lbs 1,400 lbs 15,850 lbs 10,090 lbs Base 5,398 lbs Base F/R 3,114 lbs / 2,284 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.9 Exact
3.92 6,800 lbs 1,390 lbs 15,850 lbs 10,070 lbs Base 5,413 lbs Base F/R 3,126 lbs / 2,287 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.9 Exact
3.92 6,900 lbs 1,500 lbs 15,850 lbs 10,010 to 10,050 lbs Base 5,398 lbs Base F/R 3,114 lbs / 2,284 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.9 Published range
3.92 6,900 lbs 1,490 lbs 15,850 lbs 9,990 to 10,040 lbs Base 5,413 lbs Base F/R 3,126 lbs / 2,287 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.9 Published range
3.55 6,800 lbs 1,390 lbs 14,400 lbs 8,620 lbs Base 5,413 lbs Base F/R 3,126 lbs / 2,287 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.9 Exact
3.55 6,900 lbs 1,490 lbs 14,400 lbs 8,540 to 8,590 lbs Base 5,413 lbs Base F/R 3,126 lbs / 2,287 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.9 Published range
3.21 6,800 lbs 1,400 lbs 13,800 lbs 8,040 lbs Base 5,398 lbs Base F/R 3,114 lbs / 2,284 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.9 Exact
3.21 6,900 lbs 1,500 lbs 13,800 lbs 7,960 to 8,000 lbs Base 5,398 lbs Base F/R 3,114 lbs / 2,284 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.9 Published range
3.21 6,800 lbs 1,390 lbs 12,350 lbs 6,570 lbs Base 5,413 lbs Base F/R 3,126 lbs / 2,287 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.9 Exact
3.21 6,900 lbs 1,490 lbs 12,350 lbs 6,490 to 6,540 lbs Base 5,413 lbs Base F/R 3,126 lbs / 2,287 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.9 Published range
RAM 1500 4X4 QUAD ST 6'4" BOX (Body Style DS6L41)
3.92 6,800 lbs 1,490 lbs 15,975 lbs 10,300 lbs Base 5,312 lbs Base F/R 3,103 lbs / 2,209 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.6 Exact
3.92 6,800 lbs 1,470 lbs 15,950 lbs 10,260 lbs Base 5,327 lbs Base F/R 3,115 lbs / 2,212 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.6 Exact
3.92 6,900 lbs 1,590 lbs 15,975 lbs 10,260 lbs Base 5,312 lbs Base F/R 3,103 lbs / 2,209 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.6 Exact
3.92 6,900 lbs 1,570 lbs 15,950 lbs 10,220 lbs Base 5,327 lbs Base F/R 3,115 lbs / 2,212 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.6 Exact
3.55 6,800 lbs 1,470 lbs 14,400 lbs 8,710 lbs Base 5,327 lbs Base F/R 3,115 lbs / 2,212 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.6 Exact
3.55 6,900 lbs 1,570 lbs 14,400 lbs 8,670 lbs Base 5,327 lbs Base F/R 3,115 lbs / 2,212 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.6 Exact
3.21 6,800 lbs 1,490 lbs 13,800 lbs 8,120 lbs Base 5,312 lbs Base F/R 3,103 lbs / 2,209 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.6 Exact
3.21 6,900 lbs 1,590 lbs 13,800 lbs 8,090 lbs Base 5,312 lbs Base F/R 3,103 lbs / 2,209 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.6 Exact
3.21 6,800 lbs 1,470 lbs 12,350 lbs 6,660 lbs Base 5,327 lbs Base F/R 3,115 lbs / 2,212 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.6 Exact
3.21 6,900 lbs 1,570 lbs 12,350 lbs 6,620 lbs Base 5,327 lbs Base F/R 3,115 lbs / 2,212 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.6 Exact
RAM 1500 4X4 REG ST 6'4" BOX (Body Style DS6L61)
3.55 6,350 lbs 1,390 lbs 14,400 lbs 9,030 to 9,080 lbs Base 4,958 lbs Base F/R 2,898 lbs / 2,060 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.7 Published range
3.92 6,350 lbs 1,410 lbs 14,350 lbs 8,990 to 9,040 lbs Base 4,942 lbs Base F/R 2,886 lbs / 2,056 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.7 Published range
3.92 6,350 lbs 1,390 lbs 14,325 lbs 8,950 to 9,000 lbs Base 4,958 lbs Base F/R 2,898 lbs / 2,060 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.7 Published range
3.21 6,350 lbs 1,410 lbs 13,800 lbs 8,440 to 8,490 lbs Base 4,942 lbs Base F/R 2,886 lbs / 2,056 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.7 Published range
3.21 6,350 lbs 1,390 lbs 12,350 lbs 6,980 to 7,030 lbs Base 4,958 lbs Base F/R 2,898 lbs / 2,060 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.7 Published range
RAM 1500 4X4 REG ST 8' BOX (Body Style DS6L62)
3.92 6,600 lbs 1,490 lbs 15,975 lbs 10,450 to 10,460 lbs Base 5,110 lbs Base F/R 3,026 lbs / 2,084 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.8 Published range
3.92 6,600 lbs 1,470 lbs 15,950 lbs 10,410 to 10,420 lbs Base 5,126 lbs Base F/R 3,038 lbs / 2,087 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.8 Published range
3.55 6,600 lbs 1,470 lbs 14,400 lbs 8,860 to 8,870 lbs Base 5,126 lbs Base F/R 3,038 lbs / 2,087 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.8 Published range
3.21 6,600 lbs 1,490 lbs 13,800 lbs 8,280 lbs Base 5,110 lbs Base F/R 3,026 lbs / 2,084 lbs GAWR F/R 3,900 lbs / 3,900 lbs 8 Speed Auto 8HP70 · ST p.8 Exact
3.21 6,600 lbs 1,470 lbs 12,350 lbs 6,810 to 6,820 lbs Base 5,126 lbs Base F/R 3,038 lbs / 2,087 lbs GAWR F/R 3,900 lbs / 3,900 lbs 6 Speed Auto 65RFE · ST p.8 Published range

Ram 1500

4 engines · 6,250 - 12,750 lbs · Peak payload 2,300 lbs

Back to chart top ↑
Engine Chart

3.6L V6 w/ BSG

6,250 - 7,730 lbs Engine page →

RAM 1500 4X2 CREW ST 5'7" BOX (Body Style DT1L98)
3.55 6,900 lbs 1,930 lbs 12,900 lbs 7,520 lbs Base 4,971 lbs Base F/R 2,834 lbs / 2,138 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.2
3.92 6,900 lbs 1,930 lbs 12,900 lbs 7,520 lbs Base 4,971 lbs Base F/R 2,834 lbs / 2,138 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.2
3.21 6,900 lbs 1,930 lbs 11,900 lbs 6,520 lbs Base 4,971 lbs Base F/R 2,834 lbs / 2,138 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.2
RAM 1500 4X2 CREW ST 6'4" BOX (Body Style DT1L91)
3.55 6,900 lbs 1,880 lbs 12,900 lbs 7,500 lbs Base 5,020 lbs Base F/R 2,861 lbs / 2,159 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.1
3.92 6,900 lbs 1,880 lbs 12,900 lbs 7,500 lbs Base 5,020 lbs Base F/R 2,861 lbs / 2,159 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.1
3.21 6,900 lbs 1,880 lbs 11,900 lbs 6,500 lbs Base 5,020 lbs Base F/R 2,861 lbs / 2,159 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.1
RAM 1500 4X2 QUAD ST 6'4" BOX (Body Style DT1L41)
3.55 6,900 lbs 2,100 lbs 12,900 lbs 7,730 lbs Base 4,798 lbs Base F/R 2,735 lbs / 2,063 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.1
3.55 7,100 lbs 2,300 lbs 12,900 lbs 7,730 lbs Base 4,798 lbs Base F/R 2,735 lbs / 2,063 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.1
3.92 6,900 lbs 2,100 lbs 12,900 lbs 7,730 lbs Base 4,798 lbs Base F/R 2,735 lbs / 2,063 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.1
3.92 7,100 lbs 2,300 lbs 12,900 lbs 7,730 lbs Base 4,798 lbs Base F/R 2,735 lbs / 2,063 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.1
3.21 6,900 lbs 2,100 lbs 11,900 lbs 6,730 lbs Base 4,798 lbs Base F/R 2,735 lbs / 2,063 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.1
3.21 7,100 lbs 2,300 lbs 11,900 lbs 6,730 lbs Base 4,798 lbs Base F/R 2,735 lbs / 2,063 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.1
RAM 1500 4X4 CREW ST 5'7" BOX (Body Style DT6L98)
3.55 6,900 lbs 1,770 lbs 12,900 lbs 7,370 lbs Base 5,133 lbs Base F/R 2,926 lbs / 2,207 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.3
3.92 6,900 lbs 1,770 lbs 12,900 lbs 7,370 lbs Base 5,133 lbs Base F/R 2,926 lbs / 2,207 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.3
3.21 6,900 lbs 1,770 lbs 11,900 lbs 6,370 lbs Base 5,133 lbs Base F/R 2,926 lbs / 2,207 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.3
RAM 1500 4X4 CREW ST 6'4" BOX (Body Style DT6L91)
3.55 7,100 lbs 1,870 lbs 12,900 lbs 7,300 lbs Base 5,227 lbs Base F/R 2,979 lbs / 2,248 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.3
3.92 7,100 lbs 1,870 lbs 12,900 lbs 7,300 lbs Base 5,227 lbs Base F/R 2,979 lbs / 2,248 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.3
3.55 6,900 lbs 1,670 lbs 12,900 lbs 7,250 lbs Base 5,227 lbs Base F/R 2,979 lbs / 2,248 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.3
3.92 6,900 lbs 1,670 lbs 12,900 lbs 7,250 lbs Base 5,227 lbs Base F/R 2,979 lbs / 2,248 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.3
3.21 7,100 lbs 1,870 lbs 11,900 lbs 6,300 lbs Base 5,227 lbs Base F/R 2,979 lbs / 2,248 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.3
3.21 6,900 lbs 1,670 lbs 11,900 lbs 6,250 lbs Base 5,227 lbs Base F/R 2,979 lbs / 2,248 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.3
RAM 1500 4X4 QUAD ST 6'4" BOX (Body Style DT6L41)
3.55 7,100 lbs 2,010 lbs 12,900 lbs 7,440 lbs Base 5,090 lbs Base F/R 2,902 lbs / 2,189 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.2
3.92 7,100 lbs 2,010 lbs 12,900 lbs 7,440 lbs Base 5,090 lbs Base F/R 2,902 lbs / 2,189 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.2
3.55 6,800 lbs 1,710 lbs 12,900 lbs 7,410 lbs Base 5,090 lbs Base F/R 2,902 lbs / 2,189 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.2
3.92 6,800 lbs 1,710 lbs 12,900 lbs 7,410 lbs Base 5,090 lbs Base F/R 2,902 lbs / 2,189 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.2
3.21 7,100 lbs 2,010 lbs 11,900 lbs 6,440 lbs Base 5,090 lbs Base F/R 2,902 lbs / 2,189 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.2
3.21 6,800 lbs 1,710 lbs 11,900 lbs 6,410 lbs Base 5,090 lbs Base F/R 2,902 lbs / 2,189 lbs GAWR F/R 3,900 lbs / 4,100 lbs 850RE 8 Speed · ST p.2
Engine Chart

3.6L V6 w/ BSG HFE

Up to 6,730 lbs

RAM 1500 4X2 QUAD ST 6'4" BOX (Body Style DT1L41)
3.21 6,010 lbs 1,210 lbs 11,900 lbs 6,730 lbs Base 4,798 lbs Base F/R 2,735 lbs / 2,063 lbs GAWR F/R 3,700 lbs / 4,100 lbs 850RE 8 Speed · ST p.1
Engine Chart

5.7L V8 HEMI w/ MDS

8,140 - 11,610 lbs Engine page →

RAM 1500 4X2 CREW ST 5'7" BOX (Body Style DT1L98)
3.92 6,900 lbs 1,850 lbs 17,000 lbs 11,540 lbs Base 5,054 lbs Base F/R 2,926 lbs / 2,128 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.2
3.21 6,900 lbs 1,850 lbs 13,900 lbs 8,440 lbs Base 5,054 lbs Base F/R 2,926 lbs / 2,128 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.2
RAM 1500 4X2 CREW ST 6'4" BOX (Body Style DT1L91)
3.92 6,900 lbs 1,830 lbs 17,000 lbs 11,530 lbs Base 5,072 lbs Base F/R 2,970 lbs / 2,101 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.1
3.21 6,900 lbs 1,830 lbs 13,900 lbs 8,430 lbs Base 5,072 lbs Base F/R 2,970 lbs / 2,101 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.1
RAM 1500 4X2 QUAD ST 6'4" BOX (Body Style DT1L41)
3.92 6,900 lbs 1,900 lbs 17,000 lbs 11,610 lbs Base 5,004 lbs Base F/R 2,929 lbs / 2,075 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.1
3.21 6,900 lbs 1,900 lbs 13,900 lbs 8,510 lbs Base 5,004 lbs Base F/R 2,929 lbs / 2,075 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.1
RAM 1500 4X4 CREW ST 5'7" BOX (Body Style DT6L98)
3.92 7,100 lbs 1,840 lbs 17,000 lbs 11,340 lbs Base 5,260 lbs Base F/R 3,093 lbs / 2,167 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.3
3.21 7,100 lbs 1,840 lbs 13,900 lbs 8,240 lbs Base 5,260 lbs Base F/R 3,093 lbs / 2,167 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.3
RAM 1500 4X4 CREW ST 6'4" BOX (Body Style DT6L91)
3.92 7,100 lbs 1,780 lbs 17,000 lbs 11,240 lbs Base 5,318 lbs Base F/R 3,165 lbs / 2,153 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.3
3.21 7,100 lbs 1,780 lbs 13,900 lbs 8,140 lbs Base 5,318 lbs Base F/R 3,165 lbs / 2,153 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.3
RAM 1500 4X4 QUAD ST 6'4" BOX (Body Style DT6L41)
3.92 7,100 lbs 1,970 lbs 17,000 lbs 11,470 lbs Base 5,134 lbs Base F/R 3,052 lbs / 2,083 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.2
3.21 7,100 lbs 1,970 lbs 13,900 lbs 8,370 lbs Base 5,134 lbs Base F/R 3,052 lbs / 2,083 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.2
Engine Chart

5.7L V8 HEMI w/ MDS & BSG

8,020 - 12,750 lbs Engine page →

RAM 1500 4X2 CREW ST 5'7" BOX (Body Style DT1L98)
3.92 6,900 lbs 1,740 lbs 17,000 lbs 11,430 lbs Base 5,161 lbs Base F/R 2,989 lbs / 2,173 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.2
3.21 6,900 lbs 1,740 lbs 13,900 lbs 8,330 lbs Base 5,161 lbs Base F/R 2,989 lbs / 2,173 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.2
RAM 1500 4X2 CREW ST 6'4" BOX (Body Style DT1L91)
3.92 6,900 lbs 1,690 lbs 17,000 lbs 11,390 lbs Base 5,210 lbs Base F/R 3,050 lbs / 2,160 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.1
3.21 6,900 lbs 1,690 lbs 13,900 lbs 8,290 lbs Base 5,210 lbs Base F/R 3,050 lbs / 2,160 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.1
RAM 1500 4X2 QUAD ST 6'4" BOX (Body Style DT1L41)
3.92 6,900 lbs 1,830 lbs 18,200 lbs 12,750 lbs Base 5,068 lbs Base F/R 2,970 lbs / 2,098 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.1
3.92 6,900 lbs 1,830 lbs 17,000 lbs 11,560 lbs Base 5,068 lbs Base F/R 2,970 lbs / 2,098 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.1
3.21 6,900 lbs 1,830 lbs 13,900 lbs 8,460 lbs Base 5,068 lbs Base F/R 2,970 lbs / 2,098 lbs GAWR F/R 3,700 lbs / 4,100 lbs 8HP75 8 Speed · ST p.1
RAM 1500 4X4 CREW ST 5'7" BOX (Body Style DT6L98)
3.92 7,100 lbs 1,780 lbs 17,000 lbs 11,250 lbs Base 5,323 lbs Base F/R 3,165 lbs / 2,158 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.3
3.21 7,100 lbs 1,780 lbs 13,900 lbs 8,150 lbs Base 5,323 lbs Base F/R 3,165 lbs / 2,158 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.3
RAM 1500 4X4 CREW ST 6'4" BOX (Body Style DT6L91)
3.92 7,100 lbs 1,680 lbs 17,000 lbs 11,120 lbs Base 5,417 lbs Base F/R 3,246 lbs / 2,171 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.3
3.21 7,100 lbs 1,680 lbs 13,900 lbs 8,020 lbs Base 5,417 lbs Base F/R 3,246 lbs / 2,171 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.3
RAM 1500 4X4 QUAD ST 6'4" BOX (Body Style DT6L41)
3.92 7,100 lbs 1,820 lbs 17,000 lbs 11,330 lbs Base 5,280 lbs Base F/R 3,151 lbs / 2,129 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.2
3.21 7,100 lbs 1,820 lbs 13,900 lbs 8,230 lbs Base 5,280 lbs Base F/R 3,151 lbs / 2,129 lbs GAWR F/R 3,900 lbs / 4,100 lbs 8HP75 8 Speed · ST p.2
POWERTRAIN

Towing Capacity by Engine

Your engine determines your base towing limit. Start here to see the 2019 ratings for your specific Ram 1500 setup.

The 2019 Ram 1500 was sold as both the 1500 Classic and the redesigned 1500. They use different platforms and towing ratings, so each is shown separately below.

Ram 1500 Classic

4,390 - 10,710 lbs
Highest Capacity
5.7L V8 Hemi MDS Gas
Range: 6,490 - 10,710 lbs
Max rating 10,710 LBS
3.0L V6 Turbo Diesel
Range: 7,680 - 9,260 lbs
Max rating 9,260 LBS
3.6L V6 Gas
Range: 4,390 - 7,680 lbs
Max rating 7,680 LBS

Ram 1500

6,250 - 12,750 lbs
Highest Capacity
5.7L V8 HEMI w/ MDS & BSG
Range: 8,020 - 12,750 lbs
Max rating 12,750 LBS
5.7L V8 HEMI w/ MDS
Range: 8,140 - 11,610 lbs
Max rating 11,610 LBS
3.6L V6 w/ BSG
Range: 6,250 - 7,730 lbs
Max rating 7,730 LBS
3.6L V6 w/ BSG HFE
Range: Up to 6,730 lbs
Max rating 6,730 LBS
About these numbers

Ram 1500 Classic guide-wide assumptions are not published in this source

The ratings above come straight from Ram's 2019 Ram 1500 Classic Towing Guide. This chart carries a title-level SAE J2807 compliance marker, but it does not publish the reusable note block needed for this policy strip. Treat the ratings as the hard ceiling and check the cited source guide before loading to the max.

Guide policy

Ram 1500 guide policy

Applies only to the 2019 Ram 1500 ratings on this page.

GUIDE POLICY COVERAGE
PARTIAL
This family publishes the payload formula, an SAE J2807 compliance title and warnings; no numeric load assumptions are printed.
PUBLISHED LOAD INPUTS PASSENGER / OPTIONS / TONGUE
N/A / N/A / N/A
N/A means the reviewed guide notes omit that field.
PAYLOAD METHOD GUIDE FORMULA
Payload = GVWR - Base Weight
Payload = GVWR - Base Weight · Estimated values · Rounded to nearest 10 lbs · pounds
SOURCE GUIDE REFERENCE
p.3
2019 Ram 1500 Towing Guide
VIEW PARTIAL GUIDE NOTES
PARTIAL GUIDE POLICY

Ground rules behind every 2019 Ram 1500 towing number.

These are the source-backed guide notes Ram actually prints for the Ram 1500 family in 2019.

FIG. 2019 LOAD Published Assumptions

Load assumptions the guide explicitly prints

  • No numeric passenger, options, or tongue assumptions are published in the reviewed guide notes for this family.
FIG. 2019 CALC Payload Formula

How Ram derives payload from base weight

  • Formula: Payload = GVWR - Base Weight
  • Values: Published as estimated (not guaranteed).
  • Units: pounds
  • Rounding: nearest 10 lbs.
FIG. 2019 STD Rating Standard

SAE J2807 compliance (chart title)

  • 2019 RAM DT 1500 Trailer Towing Chart - SAE J2807 Compliant p.3
FIG. 2019 WARN Warnings

Manufacturer safety warnings

  • Hitch rating, GAWRs, GVWRs and GCWRs should never be exceeded.
FIG. 2019 NOTES Policy Notes

All published notes from the 2019 towing guide

  • All weights are shown in pounds unless otherwise stated p.3
  • Payload and Max Trailer weights are ESTIMATED values and rounded to nearest 10 lbs. p.3
  • Payload = GVWR - Base Weight p.3
  • MUST include trailer (tongue) weight if towing p.3
  • Hitch rating, GAWRs, GVWRs and GCWRs should never be exceeded. p.3
  • Recommended (trailer) tongue weight determined by class hitch receiver and hardware specifications of upfit. p.3
  • Upfit or Aftermarket equipment weight(s) are not included in Base Weight and must be accounted for p.3
  • For aditional weight and trailer towing information please see 'General Information' section of Body Builders Guide p.3
NOTES: This strip shows only the guide-wide assumptions, warnings, standards, and availability limits Ram explicitly prints for this family. Missing fields stay blank instead of being inferred.
Technical Audit

Data sources

These citations show the Ram guide pages used to build the 2019 overview.

Show source pages for the 2019 guide
DOC_ID: ram-1500 DOCUMENT BASIS

2019 Ram 1500 Classic Towing Guide

Audit Scope PAGES: 1-10
PDF Creation Date 2018-09-21
DOC_ID: ram-1500 DOCUMENT BASIS

2019 Ram 1500 Towing Guide

Audit Scope PAGES: 1-3
PDF Creation Date 2018-09-07
