2019 Ram 3500 towing capacity.

The 2019 Ram 3500 tows 13,660 - 35,100 lbs depending on engine, cab, drivetrain, wheel class, axle ratio, GVWR, GCWR, and box configuration.

Find your towing capacity Look up your exact 2019 Ram 3500 configuration → Check towing capacity by VIN Decode your VIN to prefill the 2019 lookup → View full comparison chart Jump to the full rating chart →

Built from official Ram 2019 towing guides. Source pages cited below.

2019 Ram 3500
2019 TOWING RANGE
13,660 - 35,100 LBS
PEAK PAYLOAD
7,680 LBS
MAX GCWR
43,000 LBS
2019 Ram 3500 towing capacity chart
Engine Chart

6.7L I6 Cummins High Output Diesel

23,280 - 35,100 lbs Engine page

RAM 3500 4X2 CREW CAB TRADESMAN W/6.5' BOX
3.73 SRW 11,500 lbs 4,120 lbs 32,240 lbs 24,320 lbs Base 7,383 lbs Base F/R 4,450 lbs / 2,932 lbs GAWR F/R 5,500 lbs / 7,000 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.1
RAM 3500 4X2 CREW CAB TRADESMAN W/8.0' BOX
4.10 DRW 14,000 lbs 5,950 lbs 43,000 lbs 34,480 lbs Base 8,050 lbs Base F/R 4,663 lbs / 3,386 lbs GAWR F/R 5,500 lbs / 9,750 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 DRW 14,000 lbs 5,950 lbs 41,600 lbs 33,080 lbs Base 8,050 lbs Base F/R 4,663 lbs / 3,386 lbs GAWR F/R 5,500 lbs / 9,750 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 SRW 12,000 lbs 4,470 lbs 33,670 lbs 25,650 lbs Base 7,527 lbs Base F/R 4,597 lbs / 2,931 lbs GAWR F/R 5,500 lbs / 7,000 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.1
RAM 3500 4X2 CREW CAB TRADESMAN W/RAMBOX
3.73 SRW 11,500 lbs 3,970 lbs 32,240 lbs 23,350 lbs Base 7,528 lbs Base F/R 4,473 lbs / 3,055 lbs GAWR F/R 5,500 lbs / 7,000 lbs AS69RC Aisin 6 Speed · TRADESMAN · RamBox p.1
RAM 3500 4X2 REG CAB TRADESMAN W/8.0' BOX
4.10 DRW 14,000 lbs 6,570 lbs 43,000 lbs 35,100 lbs Base 7,430 lbs Base F/R 4,324 lbs / 3,106 lbs GAWR F/R 5,500 lbs / 9,750 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 DRW 14,000 lbs 6,570 lbs 41,600 lbs 33,700 lbs Base 7,430 lbs Base F/R 4,324 lbs / 3,106 lbs GAWR F/R 5,500 lbs / 9,750 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 SRW 11,500 lbs 4,520 lbs 34,630 lbs 26,990 lbs Base 6,982 lbs Base F/R 4,275 lbs / 2,707 lbs GAWR F/R 5,500 lbs / 7,000 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.1
RAM 3500 4X4 CREW CAB TRADESMAN 6.5' BOX
3.73 SRW 11,800 lbs 4,180 lbs 32,580 lbs 24,490 lbs Base 7,622 lbs Base F/R 4,683 lbs / 2,939 lbs GAWR F/R 6,000 lbs / 7,000 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.2
RAM 3500 4X4 CREW CAB TRADESMAN 8.0' BOX
4.10 DRW 14,000 lbs 5,600 lbs 43,000 lbs 34,130 lbs Base 8,396 lbs Base F/R 4,955 lbs / 3,441 lbs GAWR F/R 6,000 lbs / 9,750 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.3
3.73 DRW 14,000 lbs 5,600 lbs 41,600 lbs 32,730 lbs Base 8,396 lbs Base F/R 4,955 lbs / 3,441 lbs GAWR F/R 6,000 lbs / 9,750 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.3
3.73 SRW 12,300 lbs 4,420 lbs 33,610 lbs 25,150 lbs Base 7,878 lbs Base F/R 4,872 lbs / 3,005 lbs GAWR F/R 6,000 lbs / 7,000 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.3
RAM 3500 4X4 CREW CAB TRADESMAN RAMBOX
3.73 SRW 11,800 lbs 4,030 lbs 32,580 lbs 23,750 lbs Base 7,767 lbs Base F/R 4,681 lbs / 3,086 lbs GAWR F/R 6,000 lbs / 7,000 lbs AS69RC Aisin 6 Speed · TRADESMAN · RamBox p.2
RAM 3500 4X4 MEGA CAB BIG HORN/LONE STAR 6.5' BOX
4.10 DRW 14,000 lbs 5,420 lbs 43,000 lbs 33,020 lbs Base 8,577 lbs Base F/R 4,990 lbs / 3,588 lbs GAWR F/R 6,000 lbs / 9,750 lbs AS69RC Aisin 6 Speed · BIG HORN/LONE STAR · BOX (unspecified) p.2
3.73 DRW 14,000 lbs 5,420 lbs 41,600 lbs 32,550 lbs Base 8,577 lbs Base F/R 4,990 lbs / 3,588 lbs GAWR F/R 6,000 lbs / 9,750 lbs AS69RC Aisin 6 Speed · BIG HORN/LONE STAR · BOX (unspecified) p.2
3.73 SRW 12,300 lbs 4,220 lbs 32,710 lbs 24,060 lbs Base 8,079 lbs Base F/R 4,916 lbs / 3,162 lbs GAWR F/R 6,000 lbs / 7,000 lbs AS69RC Aisin 6 Speed · BIG HORN/LONE STAR · BOX (unspecified) p.2
RAM 3500 4X4 MEGA CAB BIG HORN/LONE STAR RAMBOX
3.73 SRW 12,300 lbs 4,080 lbs 32,710 lbs 23,280 lbs Base 8,224 lbs Base F/R 4,945 lbs / 3,279 lbs GAWR F/R 6,000 lbs / 7,000 lbs AS69RC Aisin 6 Speed · BIG HORN/LONE STAR · RamBox p.2
RAM 3500 4X4 REG CAB TRADESMAN 8.0' BOX
4.10 DRW 14,000 lbs 6,160 lbs 43,000 lbs 34,690 lbs Base 7,842 lbs Base F/R 4,620 lbs / 3,222 lbs GAWR F/R 6,000 lbs / 9,750 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.2
3.73 DRW 14,000 lbs 6,160 lbs 41,600 lbs 33,290 lbs Base 7,842 lbs Base F/R 4,620 lbs / 3,222 lbs GAWR F/R 6,000 lbs / 9,750 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.2
3.73 SRW 11,800 lbs 4,460 lbs 34,540 lbs 26,440 lbs Base 7,341 lbs Base F/R 4,551 lbs / 2,790 lbs GAWR F/R 6,000 lbs / 7,000 lbs AS69RC Aisin 6 Speed · TRADESMAN · BOX (unspecified) p.2
Engine Chart

6.7L I6 Cummins Diesel

19,500 - 22,740 lbs Engine page

RAM 3500 4X2 CREW CAB TRADESMAN W/6.5' BOX
3.73 SRW 11,500 lbs 4,260 lbs 28,300 lbs 20,590 lbs Base 7,241 lbs Base F/R 4,341 lbs / 2,900 lbs GAWR F/R 5,500 lbs / 7,000 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.1
RAM 3500 4X2 CREW CAB TRADESMAN W/8.0' BOX
4.10 DRW 14,000 lbs 6,170 lbs 30,300 lbs 22,000 lbs Base 7,833 lbs Base F/R 4,542 lbs / 3,291 lbs GAWR F/R 5,500 lbs / 9,750 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 SRW 12,000 lbs 4,620 lbs 28,300 lbs 20,450 lbs Base 7,385 lbs Base F/R 4,483 lbs / 2,902 lbs GAWR F/R 5,500 lbs / 7,000 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 DRW 14,000 lbs 6,170 lbs 28,300 lbs 20,000 lbs Base 7,833 lbs Base F/R 4,542 lbs / 3,291 lbs GAWR F/R 5,500 lbs / 9,750 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.1
RAM 3500 4X2 CREW CAB TRADESMAN W/RAMBOX
3.73 SRW 11,500 lbs 4,110 lbs 28,300 lbs 20,440 lbs Base 7,386 lbs Base F/R 4,363 lbs / 3,023 lbs GAWR F/R 5,500 lbs / 7,000 lbs 68RFE 6 Speed · TRADESMAN · RamBox p.1
RAM 3500 4X2 REG CAB TRADESMAN W/8.0' BOX
4.10 DRW 14,000 lbs 6,910 lbs 30,300 lbs 22,740 lbs Base 7,094 lbs Base F/R 4,148 lbs / 2,946 lbs GAWR F/R 5,500 lbs / 9,750 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 SRW 11,500 lbs 4,700 lbs 28,300 lbs 21,030 lbs Base 6,803 lbs Base F/R 4,155 lbs / 2,648 lbs GAWR F/R 5,500 lbs / 7,000 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 DRW 14,000 lbs 6,910 lbs 28,300 lbs 20,740 lbs Base 7,094 lbs Base F/R 4,148 lbs / 2,946 lbs GAWR F/R 5,500 lbs / 9,750 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.1
RAM 3500 4X4 CREW CAB TRADESMAN 6.5' BOX
3.73 SRW 11,800 lbs 4,340 lbs 28,300 lbs 20,370 lbs Base 7,460 lbs Base F/R 4,563 lbs / 2,897 lbs GAWR F/R 6,000 lbs / 7,000 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.2
RAM 3500 4X4 CREW CAB TRADESMAN 8.0' BOX
4.10 DRW 14,000 lbs 5,840 lbs 30,300 lbs 21,670 lbs Base 8,159 lbs Base F/R 4,818 lbs / 3,341 lbs GAWR F/R 6,000 lbs / 9,750 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.3
3.73 SRW 12,300 lbs 4,580 lbs 28,300 lbs 20,110 lbs Base 7,723 lbs Base F/R 4,751 lbs / 2,973 lbs GAWR F/R 6,000 lbs / 7,000 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.3
3.73 DRW 14,000 lbs 5,840 lbs 28,300 lbs 19,670 lbs Base 8,159 lbs Base F/R 4,818 lbs / 3,341 lbs GAWR F/R 6,000 lbs / 9,750 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.3
RAM 3500 4X4 CREW CAB TRADESMAN RAMBOX
3.73 SRW 11,800 lbs 4,200 lbs 28,300 lbs 20,230 lbs Base 7,605 lbs Base F/R 4,561 lbs / 3,044 lbs GAWR F/R 6,000 lbs / 7,000 lbs 68RFE 6 Speed · TRADESMAN · RamBox p.2
RAM 3500 4X4 MEGA CAB BIG HORN/LONE STAR 6.5' BOX
4.10 DRW 14,000 lbs 5,670 lbs 30,300 lbs 21,500 lbs Base 8,332 lbs Base F/R 4,851 lbs / 3,481 lbs GAWR F/R 6,000 lbs / 9,750 lbs 68RFE 6 Speed · BIG HORN/LONE STAR · BOX (unspecified) p.2
3.73 SRW 12,300 lbs 4,330 lbs 28,300 lbs 19,860 lbs Base 7,968 lbs Base F/R 4,805 lbs / 3,163 lbs GAWR F/R 6,000 lbs / 7,000 lbs 68RFE 6 Speed · BIG HORN/LONE STAR · BOX (unspecified) p.2
3.73 DRW 14,000 lbs 5,670 lbs 28,300 lbs 19,500 lbs Base 8,332 lbs Base F/R 4,851 lbs / 3,481 lbs GAWR F/R 6,000 lbs / 9,750 lbs 68RFE 6 Speed · BIG HORN/LONE STAR · BOX (unspecified) p.2
RAM 3500 4X4 MEGA CAB BIG HORN/LONE STAR RAMBOX
3.73 SRW 12,300 lbs 4,190 lbs 28,300 lbs 19,720 lbs Base 8,114 lbs Base F/R 4,834 lbs / 3,280 lbs GAWR F/R 6,000 lbs / 7,000 lbs 68RFE 6 Speed · BIG HORN/LONE STAR · RamBox p.2
RAM 3500 4X4 REG CAB TRADESMAN 8.0' BOX
4.10 DRW 14,000 lbs 6,390 lbs 30,300 lbs 22,220 lbs Base 7,614 lbs Base F/R 4,496 lbs / 3,118 lbs GAWR F/R 6,000 lbs / 9,750 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.2
3.73 SRW 11,800 lbs 4,610 lbs 28,300 lbs 20,640 lbs Base 7,195 lbs Base F/R 4,442 lbs / 2,753 lbs GAWR F/R 6,000 lbs / 7,000 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.2
3.73 DRW 14,000 lbs 6,390 lbs 28,300 lbs 20,220 lbs Base 7,614 lbs Base F/R 4,496 lbs / 3,118 lbs GAWR F/R 6,000 lbs / 9,750 lbs 68RFE 6 Speed · TRADESMAN · BOX (unspecified) p.2
Engine Chart

6.4L V8 Hemi with MDS

13,660 - 18,210 lbs Engine page

RAM 3500 4X2 CREW CAB TRADESMAN W/6.5' BOX
4.10 SRW 10,700 lbs 4,300 lbs 24,000 lbs 17,130 lbs Base 6,400 lbs Base F/R 3,585 lbs / 2,815 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 SRW 10,700 lbs 4,300 lbs 21,500 lbs 14,630 lbs Base 6,400 lbs Base F/R 3,585 lbs / 2,815 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.1
RAM 3500 4X2 CREW CAB TRADESMAN W/8.0' BOX
4.10 DRW 14,000 lbs 7,050 lbs 25,000 lbs 17,580 lbs Base 6,954 lbs Base F/R 3,754 lbs / 3,201 lbs GAWR F/R 5,500 lbs / 9,750 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.1
4.10 SRW 11,100 lbs 4,530 lbs 24,000 lbs 16,960 lbs Base 6,567 lbs Base F/R 3,727 lbs / 2,840 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 SRW 11,100 lbs 4,530 lbs 21,500 lbs 14,460 lbs Base 6,567 lbs Base F/R 3,727 lbs / 2,840 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 DRW 14,000 lbs 7,050 lbs 21,500 lbs 14,080 lbs Base 6,954 lbs Base F/R 3,754 lbs / 3,201 lbs GAWR F/R 5,500 lbs / 9,750 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.1
RAM 3500 4X2 CREW CAB TRADESMAN W/RAMBOX
4.10 SRW 10,700 lbs 4,160 lbs 24,000 lbs 16,990 lbs Base 6,545 lbs Base F/R 3,583 lbs / 2,962 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · RamBox p.1
3.73 SRW 10,700 lbs 4,160 lbs 21,500 lbs 14,490 lbs Base 6,545 lbs Base F/R 3,583 lbs / 2,962 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · RamBox p.1
RAM 3500 4X2 REG CAB TRADESMAN W/8.0' BOX
4.10 DRW 14,000 lbs 7,680 lbs 25,000 lbs 18,210 lbs Base 6,319 lbs Base F/R 3,396 lbs / 2,923 lbs GAWR F/R 5,500 lbs / 9,750 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.1
4.10 SRW 10,700 lbs 4,660 lbs 24,000 lbs 17,490 lbs Base 6,037 lbs Base F/R 3,402 lbs / 2,635 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 SRW 10,700 lbs 4,660 lbs 21,500 lbs 14,990 lbs Base 6,037 lbs Base F/R 3,402 lbs / 2,635 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.1
3.73 DRW 14,000 lbs 7,680 lbs 21,500 lbs 14,710 lbs Base 6,319 lbs Base F/R 3,396 lbs / 2,923 lbs GAWR F/R 5,500 lbs / 9,750 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.1
RAM 3500 4X4 CREW CAB TRADESMAN 6.5' BOX
4.10 SRW 11,000 lbs 4,270 lbs 24,000 lbs 16,800 lbs Base 6,728 lbs Base F/R 3,853 lbs / 2,876 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.2
3.73 SRW 11,000 lbs 4,270 lbs 21,500 lbs 14,300 lbs Base 6,728 lbs Base F/R 3,853 lbs / 2,876 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.2
RAM 3500 4X4 CREW CAB TRADESMAN 8.0' BOX
4.10 DRW 14,000 lbs 6,680 lbs 25,000 lbs 17,210 lbs Base 7,317 lbs Base F/R 4,058 lbs / 3,259 lbs GAWR F/R 5,500 lbs / 9,750 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.3
4.10 SRW 11,400 lbs 4,480 lbs 24,000 lbs 16,610 lbs Base 6,920 lbs Base F/R 4,017 lbs / 2,903 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.3
3.73 SRW 11,400 lbs 4,480 lbs 21,500 lbs 14,110 lbs Base 6,920 lbs Base F/R 4,017 lbs / 2,903 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.3
3.73 DRW 14,000 lbs 6,680 lbs 21,500 lbs 13,710 lbs Base 7,317 lbs Base F/R 4,058 lbs / 3,259 lbs GAWR F/R 5,500 lbs / 9,750 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.3
RAM 3500 4X4 CREW CAB TRADESMAN RAMBOX
4.10 SRW 11,000 lbs 4,140 lbs 24,000 lbs 16,670 lbs Base 6,863 lbs Base F/R 3,872 lbs / 2,991 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · RamBox p.2
3.73 SRW 11,000 lbs 4,140 lbs 21,500 lbs 14,170 lbs Base 6,863 lbs Base F/R 3,872 lbs / 2,991 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · RamBox p.2
RAM 3500 4X4 MEGA CAB BIG HORN/LONE STAR 6.5' BOX
4.10 DRW 14,000 lbs 6,630 lbs 25,000 lbs 17,160 lbs Base 7,374 lbs Base F/R 4,033 lbs / 3,341 lbs GAWR F/R 5,500 lbs / 9,750 lbs 8HP75 8 Speed · BIG HORN/LONE STAR · BOX (unspecified) p.2
4.10 SRW 11,400 lbs 4,420 lbs 24,000 lbs 16,550 lbs Base 6,978 lbs Base F/R 4,011 lbs / 2,967 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · BIG HORN/LONE STAR · BOX (unspecified) p.2
3.73 SRW 11,400 lbs 4,420 lbs 21,500 lbs 14,050 lbs Base 6,978 lbs Base F/R 4,011 lbs / 2,967 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · BIG HORN/LONE STAR · BOX (unspecified) p.2
3.73 DRW 14,000 lbs 6,630 lbs 21,500 lbs 13,660 lbs Base 7,374 lbs Base F/R 4,033 lbs / 3,341 lbs GAWR F/R 5,500 lbs / 9,750 lbs 8HP75 8 Speed · BIG HORN/LONE STAR · BOX (unspecified) p.2
RAM 3500 4X4 MEGA CAB BIG HORN/LONE STAR RAMBOX
4.10 SRW 11,400 lbs 4,280 lbs 24,000 lbs 16,410 lbs Base 7,123 lbs Base F/R 4,009 lbs / 3,114 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · BIG HORN/LONE STAR · RamBox p.2
3.73 SRW 11,400 lbs 4,280 lbs 21,500 lbs 13,910 lbs Base 7,123 lbs Base F/R 4,009 lbs / 3,114 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · BIG HORN/LONE STAR · RamBox p.2
RAM 3500 4X4 REG CAB TRADESMAN 8.0' BOX
4.10 DRW 14,000 lbs 7,280 lbs 25,000 lbs 17,810 lbs Base 6,715 lbs Base F/R 3,710 lbs / 3,005 lbs GAWR F/R 5,500 lbs / 9,750 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.2
4.10 SRW 11,000 lbs 4,600 lbs 24,000 lbs 17,130 lbs Base 6,403 lbs Base F/R 3,698 lbs / 2,704 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.2
3.73 SRW 11,000 lbs 4,600 lbs 21,500 lbs 14,630 lbs Base 6,403 lbs Base F/R 3,698 lbs / 2,704 lbs GAWR F/R 5,500 lbs / 7,000 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.2
3.73 DRW 14,000 lbs 7,280 lbs 21,500 lbs 14,310 lbs Base 6,715 lbs Base F/R 3,710 lbs / 3,005 lbs GAWR F/R 5,500 lbs / 9,750 lbs 8HP75 8 Speed · TRADESMAN · BOX (unspecified) p.2
POWERTRAIN

Towing Capacity by Engine

Your engine determines your base towing limit. Start here to see the 2019 ratings for your specific Ram 3500 setup.

Highest Capacity
6.7L I6 Cummins High Output Diesel Peak payload 6,570 lbs
Range: 23,280 - 35,100 lbs
Max rating 35,100 LBS
6.7L I6 Cummins Diesel Peak payload 6,910 lbs
Range: 19,500 - 22,740 lbs
Max rating 22,740 LBS
6.4L V8 Hemi with MDS Peak payload 7,680 lbs
Range: 13,660 - 18,210 lbs
Max rating 18,210 LBS
GUIDE NOTES PUBLISHED NOTES
8 NOTES
Limited guide notes listed below
PAYLOAD METHOD FORMULA / ROUNDING
EST. 10 lbs
Payload = GVWR - Base Weight
PUBLISHED NOTES GUIDE NOTE COUNT
8 NOTES
See the expanded guide notes below
RATING METHOD STANDARD
SAE J2807
Industry tow-rating standard
VIEW PARTIAL GUIDE NOTES
GUIDE FINE PRINT

Ground rules behind every 2019 Ram 3500 towing rating.

This 2019 Ram 3500 guide lists a limited set of assumptions, warnings, and limits. This page only shows the rules the guide states directly.

FIG. 2019 SCOPE Published Scope

What this guide actually publishes

  • Coverage: 8 published notes on the published policy pages.
  • Included: published payload method, warnings, rating standard, and any load or hitch limits stated directly by the guide.
  • Not inferred: missing heavy-trailer assumptions stay absent when the guide does not publish them.
FIG. 2019 CALC Payload Formula

How Ram derives payload from base weight

  • Formula: Payload = GVWR - Base Weight
  • Values: Published as estimated values.
  • Rounding: nearest 10 lbs.
FIG. 2019 STD Rating Standard

SAE J2807 compliance

  • 2019 RAM 3500 Trailer Towing Chart - SAE J2807 Compliant
FIG. 2019 WARN Warnings

Manufacturer safety warnings

  • GAWRs, GVWRs, and GCWRs should never be exceeded
  • Upfit or Aftermarket equipment weight not included in Base Weight
FIG. 2019 NOTES Policy Notes

All published notes from the 2019 towing guide

  • Payload and Max Trailer Weights are ESTIMATED values p.3
  • All values are shown in pounds unless otherwise stated p.3
  • Indicates Max Payload/Trailer Weight (NOTE SRW/DRW) p.3
  • Payload and Max Trailer Weight values are rounded to the nearest 10 lbs p.3
  • Payload = GVWR - Base Weight p.3
  • GAWRs, GVWRs, and GCWRs should never be exceeded p.3
  • Recommended tongue weight determined by class hitch receiver and hardware limits of upfit p.3
  • Upfit or Aftermarket equipment weight not included in Base Weight p.3
NOTES: This guide lists a limited set of heavy-trailer rules. Missing limits or assumptions are left blank instead of guessed.
Technical Audit

Data sources

These citations show the Ram guide pages used to build the 2019 Ram 3500 overview and guide-policy notes.

Show source pages for the 2019 guide
DOC_ID: ram-3500 DOCUMENT BASIS

2019 Ram 3500 Towing Guide

Audit Scope PAGES: 1-3
